| Model | | NW-307 |
| Printing | Print Method | Direct Thermal |
| Print Speed | 200mm/s,230mm/s,260m/s |
| Resolution | 576dots/line or 572dots/line |
| Printing Width | 72mm |
| Paper separator(option) | 48mm/52mm/56mm/64mm/68mm/76mm/80mm |
| Interface | USB/USB+LAN/ SERIAL +USB+LAN/SERIAL+USB+BLUETOOTH/WiFi |
| Kitchen function | Power,Paper,Erro | Support |
| LED light with beeper | Without |
| | Hanging device | Equipped |
| Memory | Input buffer | 256kbytes |
| NV Flash | 256kbytes |
| Fonts | Font A | 12x24 |
| Font B | 9x17 |
| Fonts | Chinese | GB18030,BIG5 24x24dots |
| Japanese/Korea | Support |
| User-defined | Support |
| Barcode | 1D | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 |
| 2D | QR code |
| Detection | Sensors | Paper out, paper near end, cover open, cutter jam,paper jam and black mark detection(Optional) |
| Power Supply | Input | AC 100V-240V 50/60HZ |
| Output | DC 24V/2.5A |
| Paper | Paper Type | Thermal Receipt Paper |
| Paper Width | 48mm/52mm/56mm/64mm/68mm/76mm/80mm |
| Paper Thickness | 0.06~0.08mm |
| Roll Dia | Max. Ø 83 mm |
| Paper Load | Easy paper loading |
| Paper Cut | Manual tear or Auto-cutter |
| Physical Characteristics | Working Condition | 0°C~45°C, 10%~80%RH |
| Storage Condition | -10°C-60°C,10%~90%RH |
| Dimensions | 191(D)x146(W)x12.9(H)mm |
| Net weight | 1.94kg | Gross weight | 2.14kg |
| Reliability | Printing head | 150KM |
| cutter | 1.5million |
| Accessories | | data cable,power adaptor,power code,paper roller,CD,manual,paper separator(option) |
| Packing | Individual box | Dimension 29X17X17cm(LxWxH) | 1unit/carton |
| Master carton | Dimension 62X36X52cm(LxWxH) | 12units/carton |
| OS | Emulation | ESC/POS |
| Driver | Windows XP /Vista/ Win7/Win8 /Win10/Win 2000/Win CE/OPOS/JPOS |
| SDK | Android, iOS |
After Sales Service All Kinds of Proudcts From Our Factory quarantee 18 months Warranty.
