3 Axis Vmc600 Mini CNC Milling Machine Machine Centre CNC Vertical Machining Center High Quality CNC Milling Machining Center

Product Description

cnc milling machine model VMC cnc milling machine body 850 cnc milling machine model
CNC vertical machine center vmc cnc milling machining center with high quality for metal work DRC machining center is suitable
for processing machinery and mold manufacturing field of vertical machining center, from the rough machining and finish machining
and processing requirements apply, can finish milling, drilling, tapping, boring, and a variety of processes. Vertical machining center
fearturs : 1.High quality resin sand 2. Japanese NSK bearing 3. Twaiwan spindle 4. Germany R+W coupling 5. Taiwan ball screw
and locking nut 6. Automatic lubrication system 7. Taiwan pressure cylinder 8. Chip conveyor at optional

Model	VMC 600	VMC640	VMC650
Travel parameters of 3 axis
X /Y/Zaxis travel	500/320/450mm	600/400/450mm	650/450/500mm
Spindle face to table distance	70-520mm	80-530mm	100-600mm
Distance between spindle center and column guide surface	360mm	400mm	500mm
Worktable parameters
Worktable size	800×260mm	800×320mm	900×400mm
Maximum load bearing of worktable	400kg	400kg	450kg
T Shot	3×16×75mm	3×16×100mm	5×16×75mm
Feeding parameters
X/Y/Z axis rapid movement rate	24/24/16 m/min	24/24/16 m/min	24/24/16 m/min
Feed moving velocity X, Y, Z	1-10m/min	1-10m/min	1-10m/min
Spindle parameters
Main shaft connection	Belt	Belt	Belt
Spindle taper	BT40-120	BT40-120	BT40-120
Range of spindle speed	8000rpm	8000rpm	8000rpm
Spindle motor power	5.5kW(Alternating current servo)	5.5KW (Alternating current servo)	5.5kW(Alternating current servo)
ATC paremeters
ATC capacity	12qty	16qty	16qty
Maximum tool size	Φ92mm(tool from a distance)	Φ92mm(tool from a distance)	Φ92mm(tool from a distance)
Maximum tool weight	5kg	5kg	5kg
Precision
PositionaI accuracy(JIS standard)	±0.008/300mm	±0.008/300mm	±0.008/300mm
Repeated positioning accuracy(JIS standard)	±0.005mm	±0.005mm	±0.005mm
Shape and weight
Machine size	2200×2100×2260mm	2600×1950×2400mm	2500×2100×2360mm
Weight	2400kg	2600kg	3800kg

---
