US$80,000.00-120,000.00
|
1 SETS
(MOQ)
|
Basic Info.
Automatic Grade
Automatic
Size
470mm to 2000mm Chamber Plate
Transport Package
Truck or Shipping
Production Capacity
1000 Sets Per Years
Product Description
Polypropylene Chamber filter press plate hydraulic press 1500T 2000T 2500T 3000T composite 6 columns and 4 cylinders
Hydraulic press is suitable for pressing of materials of plasticity, such as punching, bending, flanging thin stretch also can perform calibration, pressure equipment, plastic products and powder products of pressure molding. This series of hydraulic presses are suitable for various stamping processes, such as stretching, bending, forming, blanking and flanging, especially suitable for the following fields (1)Auto parts, body covers, brake pads, fuel tanks, chassis, axle housings, bumpers (2)Household appliances such as washing machines, televisions, refrigerators, etc. (3)Washing tanks, pots, stainless steel kitchen utensils and various other containers
| Specification | Unit | 2000T | 3000T | 4500T | 6000T | 8000T | 10000T |
| Nominal force | KN | 20000 | 30000 | 45000 | 60000 | 80000 | 100000 |
| Ejecting force | KN | 1260 | 1260 | 1260 | 2000 | 2000 | 3200 |
| Max. pressure of liquid | MPa | 25 | 25 | 25 | 25 | 25 | 25 |
| Stroke of slider | mm | 400 | 400 | 400 | 400 | 400 | 400 |
| Max. opening height | mm | 500 | 500 | 500 | 500 | 500 | 500 |
| Working table size | mm*mm | 1500x2500 | 1500X2500 | 1580x2550 | 2200x3500 | 2400x4200 | 2500x4500 |
| Ejecting stroke | mm | 450 | 450 | 450 | 450 | 450 | 450 |
| Speed of slider | Idle speed | mm/s | 120 | 150 | 150 | 150 | 150 | 150 |
| Working speed | mm/s | 5-10 | 5-10 | 5-10 | 5-10 | 5-10 | 5-10 |
| Return speed | mm/s | 80 | 80 | 80 | 80 | 80 | 80 |
| Press plate thickness | mm | 0.8 | 1.2 | 1.5 | 1.8 | 2 | 2 |
1. Hydraulic power part, manual and electric 2. Mechanical control part; 3. Working cylinder part; 4. Hydraulic power part; By hydraulic oil pump. The motor is connected to the plunger pump with an elastic coupling 5. Mechanical control part; It is controlled by distribution box and combination button switch 6. Tubing part: connected by high pressure seamless steel tube
>>
