Heavy Duty Gap Bed Metal Lathe Machine (CH6250C)

Product Description

heavy duty Gap Bed metal Lathe Machine (CH6250C)
PRODUCT FEATURES THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED. GEARS PRECISELY GROUND TO REDUCE NOISE. SPINDLE BORE 65MM/80MM/103MM CAN BE CHOSE. NO NEED FOR CHANGE GEAR.THE MACHINE CAN TRUN 66 KINDS OF METRIC, INCH, MODULE AND D.P. THREADS. YOU CAN CHOSE:CLUTCH IN HEADSTOCK MAKES THE LATHE MORE SAFE AND RELIABLE.

Model		DETAILS
CHB HEADSTOCK	Spindle hole	65mm
	Spindle nose	ISO-D6
	Spindle taper	Metric 70mm
	Spindle speed(Number)	(15steps)22-1800rpm
CHC HEADSTOCK	Spindle hole	80mm
	Spindle nose	ISO-D8
	Spindle taper	Metric 85mm
	Spindle speed(Number)	(15steps)24-1600rpm
CHD HEADSTOCK	Spindle hole	103mm
	Spindle nose	ISO-D11
	Spindle taper	Metric 115mm
	Spindle speed(Number)	(15steps)20-1200rpm
Model		CH6240B	CH6250B	CH6260B	CH6266B
		CH6240C	CH6250C	CH6260C	CH6266C
			CH6250D	CH6260D	CH6266D
CAPACITY	Max.swing over bed	400mm	500mm	600mm	660mm
	Max.swing over cross slide	240mm	325mm	360mm	420mm
	Max.swing over gap	540mm	630mm	730mm	790mm
	Effective length of gap	260mm
	Center Distance	1000\1500\2000\3000mm
	Bed Width	330mm
FEEDS	Longitudinal feeds range	66kinds 0.072-4.038mm/rev
	Cross feeds range	66kinds 0.036-2.019mm/rev
	Metric threads range	66kinds 0.5-28mm
	Inch threads range	66kinds 1-56inch
	Moudle threads range	33kinds 0.5-3.5mπ
	Diametral threads range	33kinds 8-56D.P
CARRIAGE	Max.travel of top slide	130mm
	Max.travel of cross slide	300mm
	Max.size of toolshank	25*25m2
TAILSTOCK	Dia.of tailstock sleeve	65mm
	Taper of tailstock sleeve	MT5
	Max.travel of tailstock	120mm
MOTOR	Main drive motor	5.5KW		7.5KW
	Rapid traverse motor	250W
	Coolant pump motor	125W
PACKING L*W*H	Center Distance(1000mm)	245*115*175cm
	Center Distance(1500mm)	295*115*175cm
	Center Distance(2000mm)	345*115*175cm
	Center Distance(3000mm)	445*115*175cm
N.W/G.W	Center Distance(1000mm)	1600/2000kg	1650/2050kg	1750/2150kg	1850/2250kg
	Center Distance(1500mm)	1800/2200kg	1850/2250kg	1950/2350kg	2050/2450kg
	Center Distance(2000mm)	1950/2350kg	2000/2400kg	2100/2500kg	2200/2600kg
	Center Distance(3000mm)	2100/2500kg	2150/2550kg	2250/2650kg	2350/2750kg
***STANDARD ACCESSORIES
3-jaw & 4-jaw
Steady rest & follow rest
Face plate
Drive plate
Thread-cutting dial
Longitudinal touch stop
Work lamp
Coolant system
Full-length splash guard(not for 3000mm length)
Foot brake and brake ribbon
Paddings
Change gears
Dead centre and centre sleeve
Oil gun
One whole set spanner
***OPTIONAL ACCESSORIES
Rapid travel
Live centre
Digital readouts(SINO)
CE-conformity(Chuck guard and Toolpost guard)
Magnetoelectrical brake
Taper cutting function

Contact person:
Tengzhou Uni-tech Co. Ltd.

Website: http://uni-techmachinery.en.made-in-china.com/


Our Services
1. Your inquiry and email will be replied within 24hours.
2. If you need to develop products with your own specification, we can help you to work it out.
3. Always be honest, never lie to customer, and never declare anything we don't have.
4. Customer First:,we offer best Quality and Service!
FAQ
1. Payment Method:
30% deposit T/T in advance, rest against the copy of B/L or before delivery.
2. Delivery Time:
one week
3. MOQ:
1 set machine.
If you need machine with your own specification, logo, packing, etc, please negotiate with us.
4. Shipping:
For machine: Usually by sea;
For documents: by international express, eg. DHL,TNT or EMS

---
