P2 P2.6 P2.9 P3 P3.91 P4 P4.81 P5 P6 P10 mm High HD Stage Advertising Outdoor Full Color Rental Panel Wall Video Advertisement Indoor LED Screen

Product Description

We are a professional manufacturer of LED display. We have excellent R&D department,independent design ability.
Our main products include led single color display, indoor full color led display screen, led display, outdoor full-color led to wireless car use screen, etc. Can be used for shopping, banking, bus station, railway stations, urban centers, airports, schools, factories, buses, taxis,creative/flexible screen and so on.
Advertising LED displays, Stadium perimeter LED screen, Mobile led display for mobile media, shopping mall LED billboard for logo showing, bank & stock exchange LED message signs for rates showing, train & bus station, airport, telecommunication LED video wall, stage performances, conference room, etc.
This outdoor display get the advantages as below,
1. 960*960mm cabinet, 25kg/pc only, light and reduce the weight for building or structures
2. Aluminum module base, for fast heat dissipation and strong against distortion in case of high temperation
3. DIrect connection between module and Hub card, ensure the stable work for the LED display
4. Thin cabinet design, 76mm thinness
5. Convenient maintenance, front and back maintenance available
6. Energy-saving design, save the power comsumption and electricity cost
The technical parameter is as below,

TECHNICAL SPECIFICATION
/ Module /
Pixel pitch	5.7	Pixel configuration		1R 1G 1B
Module size(w x h)	480*320mm	Module resolution		84*56
Pixel Density	30625dots/m2	LED type		SMD2727
/ Cabinet /
Cabinet size(w x h x d)(mm)	960*960*76	Cabinet resolution:		168*168
Material	Aluminum	Module Quantity		6
Weight(kg/Cabinet)	25	Maintenance Way		Front/Rear
Max.Power consumption(w/sqm)	900	Avg.Power consumption(w/sqm)		450
/ Technical Specification /
brightness	up to 6000nits(Adjustable)
viewing angle	Horizontal 140deg. Vertical 140deg.
Best Viewing Distance	6m-300m
Ingress Protection	IP65
Grey Level	14bit
Refresh Rate	3840
Lifetime at 50% brightness	>100,000 hours
Blind Spot Rate	≤0.0003
Input voltage	AC90V-240V
Operating temperature	"-20ºC ~ +60ºC"
Operating humidity	10% ~ 90%
Control Distance	<120 meters: UTP CAT.6 network cable (without relay). Or optical fiber transmission for over 500M-10,000M.
Source compatibility (with video processor)	HDMI, HDSDI, SDI, VGA, RJ45, YC
Operating system	Windows (XP/7/10/11)

Started in 2013, Shenzhen XD Vision is a professional manufacturer of LED display, with excellent R&D department, independent design ability. XD VISION is fully capable to provide creative and custom-made LED models beside of standard LED screens.
XD Vision contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts are running efficiently and smoothly. Moreover, delivering qualified product and offering timely pre-after service are also assured by XD VISION team.
XD Vision products include led single color display, indoor and outdoor full color led display screen, advertising poster led display, outdoor full-color led for wireless car use screen, etc. These LED display can be used for shopping mall, banking, bus station, railway stations, urban centers, airports, schools, factories, buses, taxis, monitor center, museums, theaters, cinema, sports field, so on. The types of LED display including Advertising LED displays, Stadium perimeter LED screen, Mobile led display for mobile media, shopping mall LED billboard for logo showing, bank & stock exchange LED message signs for rates showing, train & bus station, airport, telecommunication LED video wall, stage performances, conference room, etc.
XD VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by ROHS, CCC, CE, FCC, CNAS, etc. With high quality, in the past years of development, XD VISION continuous growth, XD has established the Australia Branch and LED displays have been sold to over 120+ countries all over the world.
AUSTRALIA BRANCH
Address: F3, 13-15 Kevlar Close, Braeside VIC 3195, Australia
Q&A
Q1. Could I get a sample order of led display?
A: Yes, sample order is available to check the quality.
Q2: Could we print our own logo on led display products?
A: Of course. You can send us your logo design and info to confirm before production.
Q3: Do you offer guarantee for the led display products?
A: Yes, we offer one year warranty for our products.
Q4: Do you provide technical training (installation training and user training)?
A: Yes, we offer full service, Including pre-sale, sale, after-sales service for your clientsQ5: Do you accpet other trade terms, like CIF, CFA, etc.?
A: Yes, please send us your destination address and way of shippment, we can check for you the cost for insurance and freight.
Q6: Do you custom design for different shapes?
A: Yes, we can design and manufacturer custom design LED display according to requirements.
Factory and workshop
Aging workshop and Project cases
Constrcution of Creative LED display
For Broadcast Station
For night Club
Round/circluar cylindrial creative LED display,
Flexible and Creative LED display
Round/Sphere/Hexgonal(Honey Comb) LED display
Certificates
Package and delivery

---
