| US$510.00-880.00 | 1 Piece (MOQ) |
| Brand | Huizelift | |
| Electric Forklift Truck | HZSDYG-Z-0513 | HZSDYG-Z-1013 |
| Capacity (kg) | 500 | 1000 |
| Battery (V/Ah) | 12/33 | 12/80 |
| Battery weight(kg) | 10 | 20 |
| Weight (Kg) | 175 | 217 |
| Steering wheel(mm) | 100*50 | 180*50 |
| Weight-bearing wheel(mm) | 70*60 | 80*70 |
| balance wheel(mm) | 40*26 | |
| Auxiliary balancing wheels(mm) | 30*26 | |
| load center | 400 | |
| Lifting height(mm) | 1300 | |
| Lifting mode | Electric Lift | |
| Traveling mode | Walking type | |
| Wheel | Nylon Wheel | |
| Wheelbase(mm) | 860 | |
| Front wheelbase(mm) | 380 | |
| Rear wheelbase(mm) | 670 | |
| Fork clearance(mm) | 90 | |
| Fork outer width(mm) | 535 | |
| Fork inner width(mm) | 225 | |
| Fork length(mm) | 1150 | |
| Fork size(mm) | 155*60 | |
| Overall length(mm) | 1600 | |
| Rear Rack Height(mm) | 2900 | |
| Turning radius(mm) | 1120 | |
| Max. lifting speed (full/no load) | 80-110mm/s | |
| Max. lifting speed (full/no load) | 80mm/s | |
| Lifting motor | 12V800W | |
| 1.Mast | 5.Cover |
| 2.Control handle | 6.Movable leg |
| 3.Battery indicator | 7.Fork |
| 4.Emergency stop button | 8.Frame |
