US$1,200.00-2,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
JY290VF JYP290VF JYP300VF
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Swing Over Cross Slide
165mm
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
BENCH LATHE
Hardened and ground bed way.
Large bore (38mm) spindle supported on taper roller bearing.
Independent leadscrew and feed shaft.
Power cross feed function.
Automatic feed and threading are fully interlocked.
T-slotted cross slide.
Right & left hand threads cutting is available.
Tailstock can be off set for turning tapers.
Tolerance test certificate, test flow chart included.
SPECIFICATIONS:
| MODEL | JY290VF |
| Distance between centers | 700mm |
| Swing over bed | 280mm |
| Swing over cross slide | 165mm |
| Width of bed | 180mm |
| Taper of spindle bore | MT5 |
| Spindle bore | 38mm |
| Number of spindle speeds | variable speed |
| Range of spindle speeds | 50-1800rpm |
| Range of longitudinal feeds | 0.07 -0.40mm /r |
| Range of inch threads | 8-56T.P.I 21kinds |
| Range of metric threads | 0.2 -3.5mm 18kinds |
| Top slide travel | 80mm |
| Cross slide travel | 165mm |
| Tailstock quill travel | 80mm |
| Taper of tailstock quill | MT3 |
| Motor | 1.1KW |
| Packing size | 1400 × 700 × 680mm |
| Net /Gross weight | 220kg/270kg |
| STANDARD ACCESSORIES | OPTIONAL ACCESSORIES |
3-jaw chuck
Dead centers
Reductions sleeve
Change gears
Oil gun
Some tools
| Steady rest
Follow rest
Face plate
4 jaw chuck
Live centers
Lathe tool
Stand base
Thread chasing dial
Lead screw cover
Tool post cover
Side brake |
>>
