Reconditoned Concrete Pump Truck SA*Ny 37m with HOWO Chassis

Product Description

Product Description
2020 Sa&ny howo Chassis Used Concrete Truck-Mounted Boom Pump Highly Reliable
· · Professional Supplier for Used Concrete Machine for Over 10 Years
· · Machines made by International authoritative-certificate lighthouse factory & world-class manufacturing capability · · Optimized key parts with ultra-high strength steel · · Open hydraulic system & high configuration · · With howo chassis & Putzmeister Original Pump · · Stable signal & precise control
Techinical Parameters

Brand	Sa&ny
Model	SY5271THB
Color	Red
Produce year	2012
Dimension (mm)	9600 X 2500 X 3000
Weight (kgs)	21000
Vertical reach	37m/4 section
Output (Low/High-pressure)	140/100m³/h
Pressure (Low/High-pressure)	8.3/12Mpa
Rated working pressure	32
Pumping frequency (min-1)	24/13
Tank capacity (L)	600
Filling height (mm)	1540
Hydraulic system type	Open
Max Hydraulic Pressure (bar)	360
Valve	S Valve
Inner diameter of conveying cylinder (mm)	260
Stroke of conveying cylinder (mm)	2000
Hydraulic oil cooling	Air cooling
Recommended concrete slump (cm)	12~23
Max.aggregate dimension (mm)	40
Structure type	37-4R
Placing depth (m)	33
Operation depth	21.3
vertical height	37
Slewing angle	±360°
Boom section	4
Pipe diameter (mm)	125
End hose length (mm)	3000
Lubrication mode	Energy-saving automatic lubrication

Structure type	37-4R
Placing depth (m)	33
Operation depth	21.3
vertical height	37
Slewing angle	±360°
Boom section	4
Pipe diameter (mm)	125
End hose length (mm)	3000
Lubrication mode	Energy-saving automatic lubrication

Detailed Photos

Company Profile
FAQ
1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.

---
