Twin Screw and Single Screw Laboratory Extruder

Product Description

Twin screw and single screw Laboratory Extruder
Lab twin-screw extruder is our company research for universities, research institutes and large and medium-sized enterprises engaged in various extrusion, extruded maturation, extruded variability study omnipotent models. It has gone through four generations of improvements to adapt to cereals, potato starch, protein, chemicals, plastics, rubber and other raw materials are vastly different for a variety of experiments. Powerful, easy to operate and simply of parameters adjustment, test data accurate, easy maintenance
powerful function :
Laboratory equipment are particular requirement is one machine have more function .in the laboratory ,hope one piece of equipment can complete all the experiments, however, different research institutions have different areas of research, the same research institution have different research topics, the requirements is different, adaptability and adjustable is particularly important for laboratory equipment. SYSLG30-IV experimental twin-screw extruder is researched after Germany, France, Italy, the United States, Switzerland and other developed country, and after four improved, in particular the Fourth improvement, It functions in almost perfect.
Parameters of the extruder

No.	Item	Details
1	Engine power	5.5KW
2	Engine speed-control	Frequency speed-control
3	Screw diameter	∮30
4	Screw central distance	26mm
5	Speed range	0-500rpm
6	Screw mode	Building block-combined type
7	First series L/D	11.6, 12.7 , 23
8	Material of screw	38CrMoAl nitriding treatment
9	Heating way	Electricity Heating
10	Cooling way	Water Cooling
11	Temperature scope	20ºC-300ºC
12	Temperature precision	±1.0ºC
13	Number of measuring temperature point	4 points
14	Output	5-15KG/H
15	Material of cover	SUS 304
16	Pressure scope	0-30MPa
17	Pressure precision	0.1MPa
18	Number of measuring pressure point	1 point
19	Model cooling way	Water
20	Number of raw material feeding point	3
21	Number of water feeding point	3
22	Motor Brand	Siemens

Gear box
Feeder Motor
Cutting system PLC Touch screen control
Electric Parts Control system
Our factroy pictures
