Milling Machine 3h High Speed Precision Low Cost Turret Milling Machine

Product Description

Product Performance

The VMC-M5 is a vertical turret machining center with excellent stability and rigidity. The castings of this CNC lathe are made of
cast iron with excellent sensitivity, excellent stability and no deformation problem. The spindle of the machine is made of chromium
combined with high quality steel, both cutting ability and precision of the machine are very excellent. The vertical milling head
adopts unique inverted hanging design, wihch provides excellent precision to the processing. it is also very simple to operate and
easy to brake.
The milling head adopts parts imported from Taiwan and assembled in China. The machine is compact structure and has high
flexibility. The milling head can turn around 90°, 45° before and after rotation. It equippes with manual oil pump for centralized
lubrication of work table and lifting table. It is suitable for hardware parts, machinery parts, mold and automation manipulator and
other industrial applications.

Table size	mm	254x1270
Machine load	kg	300
X/Y/Z-travel (without feeder)	mm	840/390/320
X/Y/Z-travel (with feeder)	mm	805/36/320
Milling head tilt		45° (F/B; L/R)
Ram travel	mm	540
Spindle feed ratio	mm	0.045/0.086/0.142
Taper of spindle bore		R8, NT30
Spindle motor	HP	3
Spindle speed (@50Hz)	rpm	65-4660, 16 steps
Net weight of machine	kg	1100

---
