Low Price Bench Engine Metal Lathe Precision Cutting Machine (KY280M)

Negotiable 1 Set (MOQ)

Basic Info.

Model NO.
KY280M
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Table
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Motor
0.85kw
Net Weight
200kg
Packing Size
1400*700*680mm
Spindle Bore
26mm
Cross Slide Travel
140mm
Taper of Spindle Bore
Mt4
Range of Spindle Speeds
125~2000rpm
3-Jaw Chuck
1 Set
4-Jaw Chuck(125mm)
1 Set
Swing Over Cross Slide
165mm
Transport Package
Wooden Case
Trademark
KY
Origin
China
Production Capacity
150-200 Sets /Month

Product Description

Features
1.Belt driving hobby lathe;
2.V-way bed is hardened and precision ground;
3.Super width bedway gets greater capacity;
4.Spindle is supported by precision tapered roller bearing;
5.Automatic longitudinal feed allows threading;
6.T-slotted cross slide; Adjustable gibs for slideways.
7.Top design of gearbox gets large function etc.
Specification

Model No.
KY280M

Distance between centers
700mm

Swing over bed
280mm

Swing over cross slide
165mm

Width of bed
180mm

Taper of spindle bore
MT4

Spindle bore
26mm

Number of spindle speeds
6

Range of spindle speeds
125~2000rpm

Range of cross feeds
0.02~0.28mm/r

Range of longitudinal feeds
0.07-0.20mm/r

Range of inch threads
8-56T.P.I

Range of metric threads
0.4-3.5mm

Top Slide travel
80mm

Cross slide travel
140mm

Tailstock quill travel
80mm
Taper of tailstock quill
MT2

Motor		 0.85KW

Packing size		 1400*700*680mm

Net weight		 200kgs
Standard Accessories

Splash guard		 1 pc

Chip tray		 1 pc

3-jaw chuck		 1 set

Toolbox & tools		 1 set
Optional Accessories

4-jaw chuck(125mm)		 1 set

Backplate		 1 pc

Follow rest		 1 pc

Steady rest		 1 pc

Face plate(240mm)		 1 pc

Live center MT2		 1 pc

Collet holder		 1 set

10mm turning tools(7pcs)		 1 set

Quick change tool post		 1 set

Stand		 1 set

Leadscrew cover		 1 set
