| US$1,530.00 | 1 Set (MOQ) |
| Model | 204 | 206 |
| Max.planing width | 400mm | 600mm |
| Max.press thickness | 130mm | 130mm |
| pressure gauge | 5mm | 5mm |
| Max.cutting length | 200mm | 200mm |
| Max.cut surface knife | 4mm | 4mm |
| Bottom knife cutting quantity | 2mm | 2mm |
| Motor power | 5.5KW 380V | 4KW*2 380V |
| Model | 104 | 106 |
| Max .planning width | 430mm | 630mm |
| Max .pressing thickness | 200mm | 200mm |
| Min. pressing thickness | 5mm | 5mm |
| Min .planing depth | 5mm | 5mm |
| Spindle speed | 5600r /min | 5600r /min |
| Min .planing length | 200mm | 200mm |
| Feeding speed | 9.10m /min | 9.10m /min |
| Motor power | 4kw /380v | 5.5kw /380v |
| Overall Dimensions | 900*930*1300mm | 900*1130*1300mm |
| Model | 104A |
| Max .planning width | 430mm |
| Max .pressing thickness | 200mm |
| Min. pressing thickness | 5mm |
| Min .planing depth | 5mm |
| Spindle speed | 5600r /min |
| Min .planing length | 200mm |
| Feeding speed | 9.10m /min |
| Motor power | 3kw /380v |
| Model | 1013 | 1016 | 1020 |
| Max.sawing width (MM) | 1300 | 1600 | 2000 |
| Max.sawing thickness (MM) | 200 | 200 | 180 |
| Max.planing quantity (MM) | 5 | 5 | |
| Min.planing length (MM) | 270 | 270 | |
| Saw shaft diameter (MM) | 140 | 140 | |
| Spindle speed R/Min | 3500 | 3500 | |
| Main Motor KW | 13 | 15 | 13 |
| Feeding motor KW | 3 | 1.5 | |
| Lifting motor KW | 0.75 |
| Max.working width | 400mm |
| Max.working thickness | 20-120mm |
| Max.planing depth | 5mm/3mm/5mm/5mm |
| Arbor speed | 8000r/min |
| Arbor motor power | 5.5KW 380V |
| L&R spindle speed | 7000r/min |
| L&R spindle motor | 3KW/3KW |
| Feeding speed | 9.2m/min/7.5m/min |
| Number of spindles | 4 |
| Processing width | 20-230mm |
| Processing thickness | 10-125mm |
| Feeding speed | 5-20m/min |
| Feeding power | 2.2kw |
| Bottom knife motor power | 4kw, |
| Power of the left and right spindles | 5.5kw, 5.5kw |
| Total weight | 2500kg |
| Upper knife motor power | 7.5kw |
| Cross beam lifting and lowering power | 0.75kw |
| Total power | 25.45kw |
| Air pressure | 0.3-0.4mpa |
| Min processing length(continuously feeding) | 500mm |
| planing width 120MM | 20-230mm |
| Planing thickness | 10-150mm |
| Feeding speed | 5-30m/min |
| Max Up/Down (Front table) | 5mm |
| Max Moving Amount (Front table guider) | 5mm |
| Feeding Wheel Diameter | 140MM |
| Spindle speed | 6000RPM |
| Spindle Movement(Front Bottom 40mm) | 10MM |
| Vertical Spindle Movement(Left/Right 40MM) | 30MM |
| Spindle Movement(Top 40MM) | 20mm |
| Knife Diameter(Top spindle) | 145MM |
| Knife Diameter (Front Bottom) | 120MM |
| Knife Diameter (Left/right Vertical) | 145MM |
| Motor Power (First Top Spindle) | 11KW |
| Motor Power(First Bottom Spindle) | 7.5KW |
| Motor Power(Left Vertical Spindle) | 7.5KW |
| Motor Power(Right Vertical Spindle) | 7.5KW |
| Motor Power(Second Top Spindle) | 11KW |
| Motor Power(Second Bottom Spindle) | 11KW |
| Feeding power | 5.5kw |
| UP/down motor | 0.75KW |
| Total power | 61.75kw |
| Air pressure | 0.25-0.3mpa |
| Pressure Air Demand | 0.1M3/Min |
