US$30,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Structure
Flapping-Wing UAV
Main Rotor Diameter
1910mm
Maximum Takeoff Weight
16.5kg
Specification
1690*247*495mm
Product Description
| Dimensions | 1690*247*495mm |
| Main Rotor Diameter | 1910mm |
| Maximum takeoff weight | 16.5kg |
| Maximum payload | 1.5kg |
| Empty weight | 3.7kg |
| Battery weight | 11.3kg |
| Maximum level flight speed | 100km/h |
| Economic cruising speed | 50~70km/h |
| Maximum endurance | 120min |
| Maximum range | 120km |
| Communication distance | 30km |
| Working frequency | 1360~1450MHz |
| Wind resistance performance | level 6 |
| Maximum flight altitude | 5500m |
| Hover accuracy | vertical:±2.0m(GPS)±0.1m(RTK) level:±1.5m(GPS)±0.1m(RTK) |
| Maximum ascending/descending speed | 2.5m/s,1.5m/s |
| Obstacle avoidance module | Range of obstacle perception:60m FOV:130° |
| Storage temperature | -20ºC~+60ºC |
| Operation temperature | -10ºC~+55ºC |
Q:Could your company modify the standard product depends on my request?
A:Yes. Our company is specialized in researching and designing various of special purpose vehicle and
spare parts. We can provide any product according to your demand.
Q:Can I customize the painting and logo?
A:Yes,of course, we can paint the truck as your requirements.
Q:What's your quality guanrantee or after sales service?
A:Our guarantee is 1 year, the key parts damage not caused by improper operation, it will free maintenance
and replacement. And we also provide online support, Video technical support and spare parts available. Contact us TERA foreign trade department
