| US$8,700.00-13,860.00 | 1 Piece (MOQ) |
| Model (self-hydraulic drive) | GTJZ12 |
| The maximum working height | 13.80m |
| Maximum platform height | 11.80m |
| Safe working load | 320kg |
| Extended platform safe working load | 113kg |
| Working platform size ( length ×width×height) | 2.29×1.13×1.1m |
| Overall dimensions ( length × width × height, (The guardrail is not folded) | 2495*1187*2585mm |
| Overall dimensions ( length × width × height, Folding guardrail) | 2495*1187*2050 |
| Table extension size | 0.9m |
| Minimum ground clearance | 0.1/0.02m |
| Wheelbase | 1.89m |
| Turning radius (inner wheel/outer wheel) | 0/2.2m |
| Lifting / driving motor | 24V/4.5kw |
| Lifting speed | 3-5m/min |
| Machine travel speed (closed state) | 3.5km/h |
| Machine speed (lifting state) | 0.8km/h |
| Accumulator | 4×12V/300ah |
| charger | 24V/30A |
| Maximum climbing ability | 25% |
| Maximum allowable angle of work | 1.5°/3° |
| tire | Φ 381×127 mm |
| Total Weight | 2960kg |
