Basic Info.
Model NO.
DM-40-C/DM-50-C/DM-60-C/DM-70-B/DM-80-B.
Processing Object
Animal-Derived Feed
Processing Technics
Mixing-before-Crushing
Screen Mesh
With Screen Mesh
Grinding Equipment Type
Feed Hammer Mill
Pellet Mill Type
Screw Granulator
Bulking Machine Type
Twin Screw Bulking Machine
Expanding Method
Dry Expansion
Applicable Materials Shape
Granular
Usage
Animal Poultry Livestock Feeding
Function
Aniaml Feed Puffed Pellet Machine
Raw Material
Corn Soybean Wheat
Advantage
Easy Operation High Efficiency
Processing Types
Fish Feed Processing Line
Feature
High Efficiency Low Cost
Suit for
Cow.Sheep.Pig Goose.Duck.Chicken.etc
Transport Package
Standard Export Wooden Case
Specification
Machine Weight: 350kg
Production Capacity
60 Pieces/Month
Packaging & Delivery
Package Size
75.00cm * 50.00cm * 126.00cm
Package Gross Weight
80.000kg
Product Description
fish feed pellet mill animal poultry feed pellet manufacturing machine
Product Description
Introduction of fish feed making machine Fish feed making machine is also named fish feed extruder, and it is used for processing for dogs (pet food), birds, piglets, frogs, sinking and floating aquatic feeds for fish. Fish feed making machine mainly use maize, fish powder, meat powder and some food additive as main raw material, through mixing, extruding, roasting, flavoring to get the final puffed pet food. The feed pellet size can be from 0.9mm to 10m by changing the moulds.
Product Parameters
Model
| Screw diameter
| Capacity
| Main power
| Feeding power
| Cutting power
|
DM-40-C
| 40mm
| 30-40kg/h
| 5.5kw
| 0.4kw
| 0.4kw
|
DM-50-C
| 50mm
| 60-80kg/h
| 11kw
| 0.4kw
| 0.4kw
|
DM-60-C
| 60mm
| 120-150kg/h
| 15kw
| 0.4kw
| 0.4kw
|
DM-70-B
| 70mm
| 180-200kg/h
| 18.5kw
| 0.4kw
| 0.4kw
|
DM-80-B
| 80mm
| 200-250kg/h
| 22kw
| 0.4kw
| 0.6kw
|
DM-90-B
| 90mm
| 300-350kg/h
| 37kw
| 0.6kw
| 0.8kw
|
DM-120-B
| 120mm
| 500-600kg/h
| 55kw
| 1.1kw
| 2.2kw
|
DM-135-B
| 133mm
| 700-800kg/h
| 75kw
| 1.1kw
| 2.2kw
|
DM-160-B
| 155mm
| 1-1.2t/h
| 90kw
| 1.5kw
| 3kw
|
DM-200-B
| 195mm
| 1.8-2.0t/h
| 132kw
| 1.5kw
| 3-4kw
|
Product Application
Application of the fish feed making machine This equipment uses grains,corn,soybeans meal, bone meal,meat etc. as raw materials, puff extruder particles of different shapes. It has a unique taste, rich nutrition, and delicate tissue. It is suitable for dogs, cats, fish, birds,baby animals, Shrimp, dog, cat, mink, fox and other pet food.
Features of the fish feed making machine 1.The fish feed pellets can float on water for over 20 hours.And sinking and floating aqua-feed pellets both can be made just by adjusting the feed formulation;
2.Pellet diameter is 0.9mm-15mm by changing the mold;
3.The cutter can cutting the pellets into different length;
4.The feeding speed,cutting speed,temperature all can be adjusted;
5.The machine also can make feed for pet like dog,cat with different shapes.
Machine Picture Display
