Topt-10A CE Approved Food Pharma Lab Freeze Dryer

Product Description

Product Description
Vacuum freeze dryer is widely used in medicine, pharmacy, biology research, chemical industry and food production, etc. Goods are easier for long-term preservation after freezing-drying processing, they can be restored to the original state and maintain its chemical and biological characteristics after being watered. Types : A : standard type ,B: top press type, C: manifold type , D: manifold with top press type, E :T-type
Spr
Product Parameters

Model	Unit	TOPT-10		TOPT-12		TOPT-18
Specification		Top-press 10B / 10D	Ordinary 10A /10C	Top-press 12B / 12D	Ordinar 12A /12C	Top-press 18B / 8D	Ordinary 18A /18C
Freeze-drying area	m2	0.08	0.12	0.08	0.12	0.09	0.18	0.27
Cold trap temp	ºC	<-55 (no load)
Vacuum degree	Pa	<10 (no load)
Water-capture capability	Kg/24h	3~4		3~4		6
Material tray	mm	¢180*3	¢200*4	¢180*3	¢200*4	¢200*3	¢200*4	¢200*6
Power	W	970		1070		1400
Dimension	mm	565*420*(360+430)		560*460*(710+430)		635*540*(970+430)
Material volume put in device (10mm)	L	0.8	1.2	0.8	1.2	0.9	1.8	2.7
¢12mm penicillin bottle	Pcs	560	920	560	920	990	1320	1980
¢16mm penicillin bottle	Pcs	285	480	285	480	555	740	1110
¢22mm penicillin bottle	Pcs	165	260	165	260	270	360	540
Eggplant shaped bottle 100ml/250ml/500ml/1000ml		10D/ 10C have 10A/10B no		12D/ 12C have 12A/12B no		18D/ 18C have 18A/18B no

Note:
There are the homologous products's parameters , you can refer to this table to choose the suitable product for you.
Detailed Photos
1. Freeze dried goods are easier for long-term preservation after freezing-drying processing, they can be restored to the original state and maintain its chemical and biological characteristics after being watered.
2. LCD touch screen as human-computer interface, Chinese (English) convertible interface, display drying curve.
3. TOPT-10 series freeze drying machine can store freeze-dried data for many times,experimental data can be output by a USB flash disk. Very convenient to store data and to do data analysis.
4. This vacuum freeze dryer condenser and operation panel are all stainless steel, corrosion resistant and easy to clean.
5.Ordinary model is 4 layer ,we support to customize six layer
Packaging & Shipping
Packaging-Export wooden case -Both neutral and customized packaging are available.Shipping-Usually, we ship the goods by International Express such as DHL, TNT, EMS, FedEx and UPS for small volume goods, and ship the big volume goods by air or ocean.
Company Profile
TOPTION is professional lab solution provider,and all devoted to provide the best solutions & products for global customers,who are work in biology, chemistry, pharmaceutical, environment analysis, food, academic research, etc.
TOPTION brand instrument has own high reputation in more than 70 countries and regions, provide technical support for tens of thousands organizations to solve problems within their research, special foruniversity, research institutes, industries, inspection agencies, etc.
TOPTION has passed the "ISO9001:2008 Quality Management System"certification and most of products have passed CE certification,the quality can be assured.

---
