Aeon Laser Redline CO2 Laser Cutting Machine Super Elite Nova 1490 1610 100W 130W 150W with Ruida Lightburn Software for Windows Mac Linux Acrylic Cutter

Product Description

Aeon Laser Super Nova14 is a professional co2 laser engraving and cutting machine. The working area is 900*1400mm. Super Nova14 offers the Metal RF & Glass DC in one machine. Nova14 Super's engraving speed is as fast as MIRA series machines. Also can go 2000mm/sec, the acceleration speed is 5G, has the fastest speed in its class.The structure of the Nova14 super is very strong, which makes it more steady. The machine equipped with honeycomb and blade worktable and with model 5200 chiller, makes it possible to install 100W or even 130W laser tube. The Z-axis now increased to 200mm, so it can fit in higher products. The air assists system got pressure gauge and regulator to give the users option to add a more powerful compressor to cut thicker materials. The front and back material pass-through door makes it possible to cut long materials

	Nova Super14
Working Area	900*1400mm
Machine Size	1600*1210*1025mm
Machine Weight	550kg
Work Table	Honeycomb + Blade
Laser power	80W-150W CO2 Glass Tube & 30/60w RF tube
Eletric Up&Down	200mm (7 7/8") Adjustable
Air Assist	105W Built-In Air Pump
Blower	Elite10 330W Built-In Exhaust Fan, Elite14,16 550W Built-in Exhaust Fan
Cooling	Elite10 Built-in 5000 Water Chiller, Elite14,16 Built-in 5200 Chiller
Input Voltage	220V AC 50Hz/110V AC 60Hz
Engraving Speed	2000mm/s(47 1/4"/S)
Cutting Speed	800mm/s (31 1/2 "/S)
Cutting Thickness	0-30mm(depends on different materials )
Max Acceleration Speed	5G
Laser Optical Control	0-100% Set by software
Minimum Engraving Size	Minimum Font Size 1.0mm x 1.0mm(English Letter) 2.0mm*2.0mm(Chinese Charactor)
Max Scanning Precision	1000DPI
Locating Precision	<=0.01
Red Dot Positioning	Yes
Built-in WIFI	Optional
Auto Focus	Integrated Autofocus
Engraving Software	RDWorks/LightBurn
Graphic Format Supported	AI/PDF/SC/DXF/HPGL/PLT/RD/SCPRO2/SVG/LBRN/BMP/JPG/JPEG/PNG/GIF/TIF/TIFF/TGA
Compatible Software	CorelDraw/Photoshop/AutoCAD/All kinds of Embroidery Software

---
