| US$19,000.00 | 1 Piece (MOQ) |
| Specification | ||
| General Parameter | Drive Model | 4x2 LHD |
| Curb Weight | 7990(kg) | |
| Loading Capacity | 7805(kg) | |
| Approach/Departure angle | 29/43(°C) | |
| Overall Dimensions | 6765×2499×3420(mm) | |
| Wheel Base | 3400 (mm) | |
| Overhang (front/rear) | 1190/1975(mm) | |
| Wheel Track (front/rear) | 1790/1725 (mm) | |
| Leaf Spring | 9/11+9 | |
| Axle Load(kg)(front/rear) | 5995/9995 (mm) | |
| Tire Quantity | 6 + 1 spare tire | |
| Tire Type | 8.25-16 | |
| Gearbox | 5 forwards & 1 reverse | |
| Cab | Passenger | 3 person |
| Air condition | With | |
| Max. Driving Speed | 80km/h | |
| Engine Parameter | Engine Model | YCD4F22-110 |
| Fuel | Diesel | |
| Intake Type | water cooling, turbo-charging and inter-cooling | |
| MAX Power | 110 HP | |
| Emission standard | Euro III | |
| Cylinder Number | 4 | |
| Cylinder Arrangement | In-Line | |
| Rated Speed | 2800RPM | |
| MAX Output Power | 81KW | |
| MAX Torque | 310N.M | |
| Displacement | 3.983L | |
| Specification | ||
| Superstructure | Mixer Drum Material | 16Mn |
| Drum Tank Thickness | 5 mm | |
| End Plate Thickness | 7 mm | |
| Vane Thickness | 5 mm | |
| Loading Drum Tank Capacity | 4 CBM | |
| Feeding Speed | ≥ 3 m³ | |
| Discharge Speed | ≥ 2 m³ | |
| Mixing Speed | 0-17r/min | |
| Material Remaining Ratio | ≤0.6% | |
| Reduction Gear Brand | Chinese Brand | |
| Water Supply System | 350L pressurization of the water tank. | |
| Hydraulic System Brand | Sunny brand Hydraulic Pump, hydraulic motor | |
| Cooling System Brand | KAIPENG Radiator | |
| Mixing Drum Inclination | 9ºC | |
| Collapsed Range | 60-200mm | |
| Operation Mode | The left, right and cab | |
| Standrad Configuration | Chassis, PTO,Rack,Mixing Drum,Feeding Equipment,Discharge Device,Operating System,Water Tank,Water Supply System,Hydraulic Pump,Hydraulic Motor,Reduction Gear,Hydraulic Drive System, Cooling System. | |
