Plastic PVC CPVC Garden Hose Pipe Extrusion Making and Socketing Machine

Product Description

Plastic PVC CPVC Garden Hose Pipe Extrusion Making and Socketing Machine
Description:
The PVC Pipe production line is mainly used in the area of agricultural water supply system, architectural water supply system(water supply and drainage pipe), pavement of cables and as well as different diameter and thickness of PVC Pipes. The complete PVC Pipe production line is composed by conical twin screw extruder, pipe extrusion mold, vacuum calibration tank, haul off machine, cutter and stacker, belling machine (socketing machine). The main extruder and haul off we adopts ABB inverter, vacuum pump and motors adopt high quality famous brand. Haul off machine has two claws, three claws, four claws, six claws and eight claws accord to different pipe diameters. For pipe cutting machine has saw and planetary cutting type, which additionally attached with the meter counter and intensifying device. The production line is easily installation and operation, simple maintenance with reliable quality.
Features: Complete line solution from A to Z, including raw materials. Suitable to make U-PVC, C-PVC, M-PVC pipe extrusion, PVC Pipe extrusion line; Optional to adopt conical twin screw extruder and parallel with twin screw extruder. Supply formula for the plastic PVC pipe project. Life long after sale service and technology support. Pipe Diameter range: 10-800mm. Best Economic Advice on the extrusion production line to save the production cost.
Conical Twin Screw Extruder for PVC water supply, conduit, power supply and drainage pipes.
PVC Calibration molds installed on the vacuum calibration tanks to control pvc pipes thickness.
Vacuum Calibration tanks with high quality stainless steel 304 material
Complete PVC Dual Pipe Extrusion Production Line for PVC pipes from 16mm to 63mm
Top Quality Conical twin screw with 38Cr material
Conical twin screw specially designed for PVC powders
Automatic PVC pipe online belling machine
Technical parameters:

Item	SJSZ-45	SJSZ-51	SJSZ-65	SJSZ-80	SJSZ-92
Screw diameter(mm)	45/90	51/105	65/132	80/156	92/188
Number of screw	2	2	2	2	2
Screw rotate speed(rpm)	1-45	1-45	1-35	1-37	1-33
Effective length of screw(mm)	985	1070	1440	1800	2500
Motor power(KW)	15	18.5	37	55	90
Barrel heating power(KW)	12	18	24	36	86.8
Capacity (kg/h)	120	80-150	250-300	320-400	600-800
Center height(mm)	1000	1000	1000	1000	1200
Net weight(kg)	2800	3200	4000	5000	8000
Dimension(mm)	3300x1200x2100	3600x1100x2100	4235x1520x2100	4750x1550x2460	6725x1550x2841

Spare part list (free of charge)

No.	Name	Qty.	Application
Machinery part:
1	Oil seal	1 pc.	Gearbox high-speed shaft
2	Screw unload tools	1 set	Unload screw
3	Sprayer	30 pcs.	Vacuum tank and spray tank
4	Seal	5m
5	Rubber block	20pcs.	Haul-off
6	Air pipe	5m	Cutter
7	Saw	2pcs	Cutter
8	Heating pipe	5pcs	Belling machine
Electrical part:
1	Thermocouple(3m)	4pcs.	Extruder
2	Temperature control	2pcs	Extruder
3	Small AC contactor	5pc	Electric cabinet
4	Small circuit breaker	2pc
5	Potentiometer	2pc

Exprienced Techinicians:
BORUN MACHINERY WORKSHOP:
Contact Us:
Mr. Xavier Guo
Tel: +86-512-58682331
Fax: +86-512-58682331
Mobile: +86-13405609100
