80, 000 Liters LPG Bullet Tank 40tons for Sale

Product Description

80,000 liters lpg bullet tank 40tons for sale
Tank capacity: 5000 Liters , 10000 liters, 15000 Liters, 20000 Liters, 25000 Liters, 27000 Liters, 30000 Liters, 35000 Liters, 50000 liters, 80000 liters, 100000 liters .
Technique Parameters

DIMENSIONS
Volume of Tank (cbm)	50
Tare Weight (kg)	11470
Filling Capacity (kg)	19950
Thickness of Shell (mm)	16
Thickness of Endplate (mm)	16
tank cylinder diameter (mm)	2800
External Dimensions (mm) (length×width×height)	8612*2832*3422
Material of Tank and Main Pressure Parts	Carbon Steel Q345R(carbon and low alloy steel)
Filling Medium	Liquefied Petroleum Gas
Design Pressure	1.77MPa ( 256.65 Psi)
Test Pressure	2.20MPa (319.15Psi)
Corrosion Allowance	1 mm
Medium Density	420 kg/ cbm
Bottom of Tank	metal saddle
Carried Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels.
Safety Valve of Selection Fitting: pressure relief valve, Column magnectic reversible level meter, Pressure gauge, Thermometer, Cut-off valve

Different series lpg bullet tank
Lpg bullet tank processing
Chengli Special Automobile Co., Ltd
1. We are a group company with one years quality guarantee.
2. We have advanced technology and equipments, mature experience.
3. We are leading manufacturer in China, the price of our trucks are competitive.
4. We have modern management system, the delivery time are on time.
5. We exports many trucks over the world. We have professional sales team.
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
13. Pressure Vessel
If you are interested in our trucks, pls contact me, I will send our best quotation to you.
Contact person: Krystal Zhang
Tel: +86-15171412234

---
