| Electrical PARAMETERS | No. Of Poles | 1P, 2P, 3P, 4P |
| Rated Current (In):(A) | 6A,10A,16A,20A,25A,32A,40A,50A,63A | |
| Rated voltage(Un):(V) | 220V~/230V~/240V~1P, 380V~/400V~/415V ~ (2P,3P,4P) | |
| Rated frequency:(Hz) | 50/60Hz | |
| Rated Insulation voltage Ui:(V) | 500V | |
| Rated impulse withstand voltage(1.2/50us)Uimp:(V) | 6000V | |
| Rated short-circuit capacity Icn:(A) | 6000A | |
| Energy limiting class | 3 | |
| Instaneous Tripping current: | B Type(3In~5In) C Type(5In~10In) D Type(10In~20In) | |
| Grid distance(short-circuit tests) | 45mm | |
| Electrical life | 4,000 Nos of operating cycles at rated current | |
| Mechanical PARAMETERS | Protection Degree | IP20 |
| Material group | IIIa | |
| Protection against extemal influences: | Enclosed | |
| Contact position indication | Red/Green | |
| Mechanical life | 20,000 Nos of operating cycles at rated current | |
| Contact position indicator | Yes | |
| Reference ambient calibration air temperature | 30ºC | |
| Installation | Method of mounting | On symmetrical Din rail 35mm |
| Terminal connection type | Screw terminal,Cable/U-type busbar/Pin-type busbar | |
| Terminal size top/bottom for cable | 25mm² | |
| 18-4AWG | ||
| Terminal size top/bottom for busbar | 10mm² | |
| 18-8AWG | ||
| Tightening torque | 2.5N.m | |
| Mounting | On DIN rail EN 60715 (35mm) by means of fast big clip device | |
| Operating means | Lever | |
| Connection | From top and bottom |
