Multi-Function Grain Crusher Electric Corn Mill Tree Branch Grinder

Product Description

Multi-function grain crusher electric corn mill tree branch grinder
Working Principle
The main working part of Hammer mill is the rotor with hammers.The rotor consists of main shaft, disk,hinge pin and hammers.A sieve plate is below the rotor.The motor drives the rotor to rotate at a high speed.When the materials get into the crushing cavity,they are crushed by the rotating hammers,the crushed products which meet the required size can be discharged from the sieve plate and become the final products,the products with larger size are brought back to the crushed area for being re-crushed until they reach the required size.

It is ideal for grinding grains, such as rice, corn, wheat, etc. The fineness can reach 50-120 mesh through changing different screens.
1. The Grinder mill machine is our factory new design. It has higher grinding efficiency and lower energy consumption, easy to be operated.
2. Our grinder mill is most ideal grinder equipment of all kinds grain of pulverize corn, soy bean, sorghum, barley, grain, legumes, rice, maize, dried sweet potato slices, soy bean cake etc, and also can grinding all kinds of crop stalks, such as corn stalks, peanut skins, corn stems, clover, grass, peanut shoots, rice straw, wheat straw etc.
3. This type grinder mill machine is widely used in the professions such as energy pellet factory, feed animal farm, home and so on. This final product size can arrive in more than 0.6mm range! In this range can meet you need any size sieve mesh!
When this series of grinders are used to grind corn, corn stalk, peanut shells, beanstalk and other materials such as peanut skins, clover, grass, rice straw, wheat straw, straw with the water content, there of being lower than 14% with sieves with the diameter of sieve pores being 2mm, the yield of the grinders can reach the following indexes:
We have different models,you can choose any model according to your materials.

MODEL	WS9FQ-280	WS9FQ-320	WS9FQ-350	WS9FQ-360	WS9FQ-400(With cyclone)	WS9FQ-420(with cyclone)	WS9FQ-500(with cyclone)	WS9FQ-1000(with cyclone)
Blade(PC)	gears	16	16	16	16	24	24	32
Power (KW)	1.1	2.2	3	5.5	7.5	11	15	22
OUTPUT(KG/H)	100-150	300-500	500-700	700-900	1000-1200	1200-1500	1500-2000	5000-6000

---
