US$670.00-900.00
|
1 Square Meter
(MOQ)
|
Basic Info.
Pixel Configuration
1R, 1G, 1B
Display Function
Video Display, Image & Text Display, Text Display, Market Display
Average Power Consumption
≤300W/M2
Scanning Mode
Constant Current Drive
Display Type
LED Video Display
Certification
CE, RoHS, CCC
Module Resolution (W×h)
128×64
Module Size (W×h) (mm)
500×250
Unit Size (W×h×d) (mm)
500×500×80/500×750×80
Unit Resolution (W×h)
96×96
Unit Weight (Kg)
34 Kg /M2
Maintenance Method
Front Maintenance
Cabinet Material
Die-Cast Aluminum
Product Description
Product Description
Series outdoor LED products have the characteristics of high contrast, high refresh, wide viewing Angle, high reliability of fault detection, pre/post maintenance, etc., the picture is clear and bright under direct sunlight, and the display effect is natural and real, which is very suitable for outdoor advertising media.
Simple appearance, light and thin box design, stable and reliable IP66 high protection grade, full waterproof module, sealed design, wireless plug, adapt to a variety of harsh environments All aluminum chassis, engine structure design, increased contact area with air, high heat dissipation efficiency 3840Hz ultra-high refresh frequency, the screen display is delicate and smooth High brightness, high contrast, excellent visual perception Support pre/post maintenance, adapt to all installation environments, easy maintenance It can be stitched in any direction and size, and the picture is uniform without stitching
| Model | LED Display Terminal | EV100039 |
| Module Composition | Pixel Composition | 1R1G1B |
| | LED Packaging | SMD1921 |
| | Pixel Pitch (mm) | 3.91 |
| | Module Resolution (W×H) | 128×64 |
| | Module Size (W×H) (mm) | 500×250 |
| Cabinet | Unit Size (W×H×D) (mm) | 500×500×80/500×750×80/500×1000×80 |
| | Unit Weight (kg) | 34 kg /m2 |
| | Unit Flatness (mm) | ≥98% |
| | Maintenance Method | Front maintenance |
| | Protection Level | IP66 |
| | Cabinet Material | Aluminum profile |
| | Flatness | ≤0.1mm |
| Optical Parameters | Pixel Correction | Support brightness and chroma point by point correction |
| | Brightness (cd/m2) | Standard 4500 (Customizable to 11000) |
| | Color Temperature (K) | 9000 (adjustable from 2000K to 12000K) |
| | Visual Angle | 160° horizontal / 120° vertical |
| | Brightness Uniformity | ≥98% |
| | Color Uniformity | Within ±0.003Cx, Cy |
| | Maximum Contrast | 5000:1 |
| Electrical Parameters | Peak Power Consumption (W/m2) | ≤750 |
| | Average Power Consumption (W/m2) | ≤300 |
| | Power Supply Requirement | 110-220V/200-240V |
| Processing Performance | Driving Method | Constant current drive |
| | Frame Change Frequency | 50/60Hz |
| | Refresh Rate (Hz) | 1920/3840 |
| | Processing Depth (Bits) | 14-16 |
| | Brightness Control | Manual/automatic/programmed |
| Usage Parameters | Typical Value Of Life (H) | ≥100000 |
| | Operating Temperature/Humidity Range | -20ºC -50 ºC / 10%-90%RH (non-condensing) |
| | Storage Temperature/Humidity Range | -40ºC -80 ºC / 10%-90%RH (non-condensing) |
| | Installation Method | Outdoor fastening |
Note: The above parameters are typical values of the product. Different batches of products may vary. The actual parameters of the product are subject to the factory inspection report. The product will be continuously optimized and iterated during the production process, and the product specification sheet will be adjusted at any time. Consult regional distributors before purchasing. For customized products, the specification sheet needs to be reissued. Company Profile
>>
