30m Boom Truck-Mounted Concrete Pump

US$125,000.00-135,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

SYM5190THBDZ 30

Type

Concrete Pump

Shotcrete Type

Wet

Machining Process

Hydraulic

Structure

Cylinder Type

Productivity

120m²/h

Feeding Height

1400mm

Vibrating Amplitude

2.0mm

Certification

ISO9001: 2000

Condition

New

Color

Optional

Empty Weight

19000kg

Chassis Model

Zz5207m521gd1

Engine Model

Mc07.24-40

Engine Power

176/2300 Kw/Rpm

Transport Package

Nude Packing

Specification

10650x2500x3700mm

Trademark

S ANY

Origin

China

HS Code

87059091

Production Capacity

20units/ Month

Product Description

Made in China 30m woking aloft truck mounted concrete pump

1. MERCEDES BENZ CHASSIS COMCRETE PUMP TRUCK
2. Vertical reach: 30m

Model Unit

Pump Unit	Max. Theor. output	m3/h	140/90
	Max. Theor. concrete output Pressure	MPa	7/11
	Rated working pressure	MPa	35
	Pumping frequency	min-1	27/17
	Hopper capacity	L	550
	Filling height	mm	1540
	Hydraulic system type		opened loop
	Distribution valve		S valve
	Oil cylinder dia.×stroke	mm	φ130×2100
	Concrete cylinder dia.×stroke	mm	φ230×2100
	Hydraulic oil cooling		Wind cooling
	Recommended concrete slump	cm	12~23
	Max. aggregate dimension	mm	40
Boom Section	Structure type		43X-5RZ
	Placing depth	m	43
	Max. horizontal distance	m	39
	Max. placing depth	m	30.46
	Slewing angle		±270°
	Boom number		5
	The length of boom section	mm	8350/7250/7050/7930/8420
	Sections folding angle		90°/180°/180°/240°/200°
	Pipe diameter	mm	125
	End hose length	mm	3000
	Min. height of opening placing boom	mm	9100
	Outriggers span (front×rear×side)	mm	8220×8800×8900
