Super-Above Truck Crane, 100ton Hydraulic Mobile Crane with Spare Parts in Stock

Product Description

Super-above 100Ton Truck Crane Hydraulic Mobile Crane for sale
Super-above Truck crane is widely used for the lifting operations in general engineering projects, such as construction site, urban renewal, communication and transportation, ports, bridge, oilfields and mine, and complex working environments. * 6-section boom of 64 m with U-type profile is adopted; the max. lifting load is 100 t; the max. lifting height is 92.6 m; the max. working radius is 62 m; The performance takes the lead comprehensively. * Low speed large torque power transmission system, contributes to perfect combination of optimal power and optimal economical efficiency, leading to more than 12% reduction in fuel consumption and 10% improvement in grade ability. * SATC100 is also the first four-wheel driven truck crane domestically, which can meet the need under various road conditions.Chassis rear hydraulic controlled follow-up steering technology, realizate highway and small turning two steering modes, ensure stable and reliable of vehicle at high speed, travelling at lower speed is flexible.
Specifications of 70tons Hydraulic Truck Crane

Description	Unit	Parameter value
Overall length	mm	13900
Overall width	mm	2800
Overall Height	mm	3575
Wheel Base	mm	2304+2075
Total vehicle mass in travel configuration	kg	43000
Engine Model	WD615.338
Engine rated power	kw/(r/min)	276/2200
Engine rated torque	N.m/(r/min)	1500/1400
Engine rated rotational speed	r/min	2100
Max. travel speed	km/h	80
Min. steady travel speed	km/h	3
Min. turning diameter	m	24
Min. turning diameter at boom tip	m	29
Min. ground clearance	mm	327
Max. grade ability	%	40
Approach angle	°	19
Departure angle	°	11
Braking distance (at 30 km/h, full load )	m	≤10
Oil consumption per 100km	L	45
Max. total rated lifting capacity	t	70
Min. rated working radius	m	3
Turning radius at turntable tail	mm	3550
Max. load moment Base boom	KN.m	2303
Max. load moment Fully-extended boom	KN.m	1129
Max. load moment Fully-extended boom + Jib	KN.m	580.2
Hoist height Base boom	m	11.8
Hoist height Fully-extended boom	m	44.2
Hoist height Fully-extended boom + Jib	m	59.4
Boom length Base boom	m	11.6
Boom length Fully-extended boom	m	44.5
Boom length Fully-extended boom + Jib	m	59.5
