Product Details
Product Description
Product Description
Chinese 5 ton front wheel loader VS SDLG 956L 5 ton wheel loader price
POWERFUL CUMMINS ENGINE
AUTO TRANSMISSION
JOYSTICK CONTROL
ROPS&FOPS CABIN
VARIETY WITH ATTACHMENT
CONVENIENT MAINTENANCE
Items
| Parameters
|
Engine power
| 162KW/2200r/min
|
Overall dimension(LXWXH)
| 7600mmX3000mmX3350mm
|
Operating weight
| 16500KGS
|
Rated loading capacity
| 5000KGS
|
Bucket capacity
| 3M3
|
Bucket width
| 3000mm
|
Wheelbase
| 2760mm
|
Treed width
| 2250mm
|
Dumping height
| 3180mm
|
Dumping reach
| 1250mm
|
Turning angle
| 35°±1°
|
Max. climbing gradient
| 28°
|
Turning radius
| 6650mm
|
Max. breakout force
| 145kN
|
Max. torque
| 745.3N.m
|
Lifting time
| ≤ 6.8s
|
Hydraulic cylinder time
| ≤ 12.55s
|
Specification of tire
| 23.5-25
|
Travel speed
| Forward gear I
| 11.5km/h
|
Forward gear II
| 38km/h
|
Reverse gear I
| 16km/h
|
| OVERALL DATA |
| Bucket Capacity | 3.0m³ |
| Rated Payload | 2500kg |
| Operating Weight | 17900±300kg |
| Traction Force | 160±3kN |
| Breakout Force | 135±3kN |
| L×W×H | 10320×3034×3380mm |
| ENGINE&ELECTRICAL SYSTEM |
| Maker/Model | WEICHAI/WD10G220E21 |
| Emission Standard | EPA (TierⅡ)/NationalⅡ |
| Engine Type | 4 Stroke,Turbocharged,Water-cooled,Direct Injection,Diesel Engine |
| Rated Power | 162kW(220hp)/2200rpm |
| Maximum Torque | 860N·m/1400-1600rpm |
| Bore x Stroke (mm) | 126×130 |
| No. of Cylinders/Displacement | 6/9.726L |
| Compression Ratio | 17 |
| Air Cleaner | Three Stage Air Cleaner with Cyclone Pre-cleaner |
| Alternator | 55Amp |
| Battery | 2-24V/120Ah |
| Starting Motor | 24V/7.5kW |
| Heating Capacity (W)-OPTIONAL | 5000W |
| Cooling Capacity (W)-OPTIONAL | 4700W |
1.Exclusive patent: 6 proprietary technologies are applied in our loaders make them more fuel-efficient and safety,such as the dust-proof layer make the axle more durable.
2.Details in structure: Bigger hinge pin and hinge bearing raise the carrying capacity, machine more powerful. The exclusive dust-proof layer and sealed articulated points make the loader more durable. 3.Novel appearance and humanized design: Cabin with broad view.Single (double)-handle pilot control system, electronic control gearshift to ensure easy operation and more comfortable.
4.Hydraulic systems: To adopt confluence of double pumps and equivalents unloading hydraulic systems, rational use of engine power, reduce energy consumption effectively. Independent transmission oil and hydraulic oil cooling improve the hydraulic system stability.
5.Optional attachment: Floating forks, tire chain, log grapple, block fork, snow blade, grass fork, enlarged bucket and teeth etc.
>>
