Double Turret CNC Lathe with Optional Fanuc and Knd Controllers

Product Description

Introducing the state-of-the-art Double Side Turrets Turning CNC Lathe Machine, meticulously designed for precision and efficiency. This advanced piece of machinery elevates your production capabilities with unparalleled accuracy and speed, ensuring your operations are always ahead of the curve.
Product Description
Introducing our state-of-the-art Double Side Turning CNC Lathe Machine, a masterpiece designed to revolutionize your machining experience. This innovative machine seamlessly integrates cutting-edge technology for precision and efficiency in every operation.
It is expertly engineered to primarily focus on the turning of shaft workpieces, providing superior results and unmatched accuracy from both sides, ensuring each piece meets the highest standards of quality and precision.
For those seeking enhanced functionality, our CNC lathe comes equipped with an optional Y-axis milling power head turret. This addition allows for expanded capabilities, providing versatility and adaptability to meet diverse machining needs.

machining details
MODEL	WORKPIECE LENGTH	X/Z WORKPIECE LENGTH
XSC500	500	300/250X2
XSC700	700	300/350X2
XSC800	800	300/400X2
XSC1000	1000	250/400X2
XSC2000	2000	350/900X2
XSC3000	3000	400/1400X2

machine details
PARAMETER	UNIT	XSC800
Machine Type		45°slant bed
Spindle Type		single spindle + center holder
Tool Holder Type		Electric/servo
Tool Holder Station		4/8/12 station
MAX. Workpiece Length	mm	800
MAX. Workpiece Diamete mm		72/120/160/200
X Axis Stroke Distance	mm	300
Z AxisStroke Distance	mm	400*2
X/Z Axis Fast Move	mm/min.	45
Processing Coaxiality Spindle Power	mm	24
	kw	5
Spindle Speed	mm/min	2000/1000/500

Detailed Photos
| DETAIL PRESENTATION

AUTOMATION FUNCTIONS
Our advanced machinery independently develops and produces sophisticated upper and lower silos, complete with cutting-edge features such as automatic axial positioning, precise workpiece in-place detection, seamless automated interfaces, and efficient automatic counting for optimal productivity.


SPINDLE & TURRET
Featuring an imported P4 grade spindle renowned for its outstanding stability and high rigidity, this component offers exceptional precision. Hydraulic clamping ensures a robust clamping force, guaranteeing superior performance and reliability.




GRAVITY ROLLER CONVEYOR
Designed for versatility, it seamlessly integrates with roller conveyors and automated robotic operations, significantly enhancing work efficiency and streamlining processes.




CNC SYSTEM
The CNC system boasts a dual-channel bus absolute value servo system, eliminating the need for reset upon startup. You can power it on and utilize it as required, ensuring convenience and unimpeded operation.




| PRODUCT SHOOTING


The center drive dual-tooling turret series offers remarkable precision with coaxiality of both ends at an impressive 0.01 mm. The fully automatic production process is complemented by an upgradable multifunctional power turret, setting new standards in innovation and efficiency.
