HiDON Factory Price 4.0 Inch Octa-Core 4G IP68 Navigation Speaker NFC PTT Truly Industrial-Grade 4W DMR Phone Mini Rugged Phones
Model NO.: HC03
Product Description
| CPU: | Mediatek MT6762 Octa-core 2.0GHz |
| Operation System: | Android 9.0 |
| Display & Touch panel: | 4.0 inch Capacitive Multi-touch screen, IPS 480*800 Pixels |
| Network: | 4G LTE Networks: GSM: B2/B5/B8/B3=1900/850/900/1800Mhz,
3G WCDMA: B1/B2/B4/B5/B8, CDMA2000:BC0 800Mhz;
TDD-LTE: B38/B39/B40/B41=2600/1900/2300/2500MHZ;
FDD LTE: B1/B3/B5/B8=2100/1800/850/900MHZ |
| Two Cameras: | Front-facing 8.0M camera, Rear-Facing 13.0M cmos Camera |
| Memory & Storage: | 4GB ram + 64GB ROM |
| Wireless Network: | 802.11 a/b/g/n 2.4G+5.0Ghz and Blutooth:V2.1+EDR,V3.0+HS,V4.0BLE |
| Navigation: | Support GPS+GLONASS+BEIDOU |
| Battery: | 7.6V/3000mAh li-thium Battery |
| Rugged Durability: | Waterproof and dustproof rate: IP68; Ruggedness:comply with MIL-STD-810G |
| Speaker: | 2W,Φ36/8Ω,Professional super-loud speaker |
| NFC function: | 13.56MHZ,support ISO1444A/B,ISO1593 |
| DMR Waikie-Talkie and PTT Function: | 4W High Intercome Power,operating frequency range: U range 400-470MHZ;the intercom distance reach max 2.0-8.0KMs; PTT function is also available |
| Temperature: | work Temp.:-30 to 65 degree, Storage Temp.:-40 to 70 degree, Weight: about 333g |
| M6 Expansion port: | 13-pin expansion port,support external micphone or external cameras,etc. |
| Dimension: | 161mm*73.3mm*30.4mm (Excluding antenna), Weight: about 361g |
1.CPU: Mediatek MT6762 Octa-core 2.0GHz;
2.Operation System: Android 9.0;
3.Display: 4.0 inch Capacitive Multi-touch screen, IPS 480*800 Pixels;
4.4G LTE Networks: GSM: B2/B5/B8/B3=1900/850/900/1800Mhz,
3G WCDMA: B1/B2/B4/B5/B8, CDMA2000:BC0 800Mhz;
TDD-LTE: B38/B39/B40/B41=2600/1900/2300/2500MHZ;
FDD LTE: B1/B3/B5/B8=2100/1800/850/900MHZ;
5.Two Cameras: Front-facing 8.0M camera, Rear-Facing 13.0M cmos Camera;
6.Memory & Storage: 4GB ram + 64GB ROM;
7.Wireless network: 802.11 a/b/g/n 2.4G+5.0Ghz and Blutooth:V2.1+EDR,V3.0+HS,V4.0BLE;
8.Navigation: Support GPS+Glonass+Beidou;
9.Battery: 7.6V/3000mAh li-thium Battery;
10.Rugged Durability: Waterproof and dustproof rate: IP68; Ruggedness:comply with MIL-STD-810G.
11.Speaker: 2W,Φ36/8Ω,Professional super-loud speaker;
12.NFC function: 13.56MHZ,support ISO1444A/B,ISO1593;
13.DMR Waikie-Talkie and PTT Function: 4W High Intercome Power,operating frequency range: U range 400-470MHZ;the intercom distance reach max 2.0-8.0KMs; PTT function is also available;
14.Temperature: work Temp.:-30 to 65 degree, Storage Temp.:-40 to 70 degree, Weight: about 333g.
15.M6 Expansion port:13-pin expansion port,support external micphone or external cameras,etc.
16.Dimension: 161mm*73.3mm*30.4mm (Excluding antenna), Weight: about 361g.
!!!Please note: The provided Price in this website is meaningless, welcome to ask for real price by email or by inquiry.
Highton Electronics CO., LTD is the first and professional rugged phones manufacturer in China. We have manufactured rugged phones since 2008.
Our OEM factory has 200-300 employees, covering 5000 square meters, having 6 SMT machines and 8 production assembly line. We can assembly about 10000pcs Rugged phones per month and our factory was approved by ISO9001 certificate, strictly fulfill "7S" quality system.
We are making OEM & ODM orders for many domestic and foreign brands. We have good partnership with many CPU suppliers like Mediatek, Qualcomm agents. In general, for same quality, our price should be the best in China!
!!! We are striving to become your best choice if you buy rugged phones in China.
Warranty Policy:
| 1-year Factory warranty
|
Payment Terms:
| Bank transfer T/T, or Western Union or Paypal.
For samples, prepay the full sample cost;
For Bulk Order, prepay 30% deposit, the balance will be available before the shipment.
|
Delivery Time:
| For samples, it is about 1-4 working days depending on the stock status and materials preparing condition;
For Bulk Order, it takes about 7-20 working days, but try to complete the order as soon as possible.
|
OEM & ODM
| Welcome, firstly tell us your expected specification, and then we will try to meet your demands within our skill ability scope. We are making OEM orders for many brands.
|
Packing
| Color Box, Standard Packing Box
|
!!! If this product can not meet your needs, please visit our official website, and we could provide customized products for you.
*.We try to reply your inquiry as soon as possible;
*.Experienced Staffs answer your questions in fluent English;
*.OEM & ODM are welcomed after receiving your specification;
*.Special Discount and Protection of sales are provided by us;
*.Most parts are produced by ourselves, so can help to reduce product cost.
Note:
Highton Electronics CO., LTD manufactures all kinds of 4 to 12 inch Android or Windows rugged tablets or PDA Handhelds and other smart terminals, With many Optional functions: NFC, Fingerprint scanner, Barcode scanner, IC/ID card reader, LF/UHF RFID, walki-talkie/DMR, IRIS, Thermometer, satellite phone, ATEX/explosion-proof, your own module, and many other functions you want.
Optional interface: RJ45 Ethernet Lan port, serial port, CAN port........ If our existing products can’t meet your demands, we can develop and customize new products for you. Please feel free to contact with us.
For same quality and same configuration, our price is trying to be the BEST around the world.
Attention : SALES8 HIGHTON
Skype ID : szhighton8
Phone/ WhatsApp/ Wechat : +86 19926547376
Email : Sales8# (# means @)
Looking forward to your early contact!!!
