8FE+2FE 8*100M 2*100M OEM/ODM DIN rail DC48~58V IP40 Gigabit 8 Port Industrial Switch PoE
Provider Mode Ports
|
Fixed port
| 2*1000Base-X SFP, 8*10/100/1000Base-T PoE
|
Power interface
| Phoenix terminal, dual redundant power supply
|
LED Indicators
| PWR, OPT, NMC, ALM
|
Reset
| DIP switch reset |
Cable Type&Transmission Distance
|
Twisted-pair
| 0-100m(CAT5e,CAT6)
|
Single mode optical fiber
| 20/40/60/80/100km
|
Multi mode (optical) fiber
| 550m
|
Net Topology&Networking Scale
|
Star topology
| Support
|
Bus topology
| Support
|
Tree topology
| Support
|
Hybrid topology
| Support
|
Electrical Specifications
|
Input voltage
| DC12-58V
|
Power consumption
| Non PoE<6W;PoE<246W
|
Voltage Alarm
| Support |
PoE (Optional)
|
PoE port
| 1~8
|
PoE Protocol
| 802.3AF ,802.3AT
|
PoE Pin Assignment
| 1,2,3,6
|
PoE Mode
| Standards and non-standards are support optional
|
Remote PD Reset
| Support Optional |
Layer 2 Switching
|
Switching capacity
| 26G
|
Packet forwarding rate
| 19.34Mpps
|
MAC address table
| 16K
|
Buffer
| 2M
|
Forwarding delay
| <5us
|
MDI/MDIX
| Support
|
Flow control
| Support
|
Jumbo Frame
| 10K Bytes
|
WatchDog
| Support |
| Reset | Support |
| Port Isolation | Support Optional |
Environment
|
Operating temperature
| -40ºC-+75ºC
|
Storage temperature
| -40ºC~ +85ºC
|
Relative humidity
| 5%~95% (non-condensing)
|
Thermal methods
| Fan-free,natural cooling
|
MTBF
| 100,000 hours
|
Mechanical Dimensions
|
Product size
| 143X104X48mm
|
Installation method
| Din-rail
|
Weight
| 0.5KG around
|
EMC&INGRESS Protection
|
IP level
| IP40
|
Surge protection of power
| IEC 61000-4-5 Level X (6KV/6KV)(8/20us)
|
Surge protection of ethernet port
| IEC 61000-4-5 Level X (4KV/4KV)(10/700us)
|
RS
| IEC 61000-4-3 Level 3 (10V/m)
|
| EFI | IEC 61000-4-4 Level 3 (1V/2V) |
| CS | IEC 61000-4-6 Level 3 (10V/m) |
| PFMF | IEC 61000-4-8 Level 4 (30A/m) |
DIP
| IEC 61000-4-11 Level 3 (10V)
|
ESD
| IEC 61000-4-2 Level 4 (8K/15K)
|
Free-Fall
| 0.5m
|
