Full Color Big Digital Outdoor Indoor SMD Advertising P2.5 P3 P4 P5 P6 P8 P10 LED Display Screen Sign Video Wall Electronic Signage Poster Pole Panel Billboard

Product Description

Specification

OF/OFR	OF2.5	OF3	OF3.076	OF3.91	OF4	OF4.81	OF5
Pixel Pitch(mm)	2.50	3.00	3.08	3.91	4.00	4.81	5.00
Pixel Matrix Per Sq.m	160000	111111	65436	65436	62500	62500	40000
Pixel Configuration	SMD1415	SMD1415	SMD1415	SMD1921	SMD1921	SMD1921	SMD1921
Brightness (nits)	5000	1800	5000	4000	5000 5500	4000	5500
Scan	1/16	1/16	1/13	1/16	1/10 1/8	1/13	1/8
Module Dimension	160x160mm	192x192mm	320x160mm	250x250mm	320x160mm 256x128mm	250x250mm	320x160mm
Cabinet Weight	46kg / 101lb (Iron)	46kg / 101lb (Iron)	45kg / 99lb (Iron)	44kg / 97lb (Iron)	44kg / 97lb (Iron)	43kg / 95lb (Iron)	43kg / 95lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m
Cabinet Dimension	960x960mm (Cabinet size can be changed according to module size)
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

OF/OFR	OF6	OF6.6	OF8	OF10S	OF10D	OF16S	OF16D
Pixel Pitch(mm)	6.00	6.67	8.00	10.00	10.00	16.00	16.00
Pixel Matrix Per Sq.m	27777	22500	15625	10000	10000	8000	10000
Pixel Configuration	SMD3535	SMD2727	SMD3535	SMD3535	DIP346	SMD3535	DIP346
Brightness (nits)	5500	5500	6500	6500	1000	8000	10000
Scan	1/8	1/6	1/3	1/2	1/2	1/1	1/1
Module Dimension	192x192mm	320x160mm	320x160mm	320x160mm	320x160mm	256x256mm	256x256mm
Cabinet Weight	42kg / 93lb (Iron)	42kg / 93lb (Iron)	41kg / 90lb (Iron)	40kg / 88lb (Iron)	40kg / 88lb (Iron)	46kg / 101lb (Iron)	46kg /101lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m
Cabinet Dimension	960x960mm (Cabinet size can be changed according to module size)
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

Company Profile LEDFUL is a top LED display manufacturer with 13 years rich experience providing 3 years warranty.
We concentrate on LED Poster, Transparent LED screen, Outdoor & Indoor commercial LED billboard,
Rental LED screen, Sports LED display.
Certifications Due to our best balance of quality & price with strong reputation, our LED displays are exported to 83
countries in Europe, America, Asia, Africa, and Oceania with successful 5600 projects. Besides LEDFUL
obtained CE, FCC, RoHS, CCC, UL, ETL, EMC, ISO9001 certificates. A state-of-the-art manufacturing
and testing facility ensures LEDFUL products of the high and stable quality.
Each product goes there 16 monetary procedures 23 operating procedures in 1500 tests and experiments.
Packaging & Shipping All employees are honest, responsible and diligent. Dedicated to professional,
high efficient and caring features, our experienced sales engineers listen to you,
think more for you.
In addition, take good care of each detail of your order, packages and shipping.
We also welcome deep customized, OEM, ODM orders and distributors application.
LEDFUL is a trusted one-stop LED display solution provider with more designs and more solutions.
Our partners are media advertising, audio, video & light, retail, property, religion, sports, event, studio.
Front service, double sided, column, flex, curved, sphere, 90 degrees, any irregular shaped LED display
are available.
Our corporate philosophy is to maximize the value for our customers and to provide the best service for
our customers. FAQ
1.Q:how about the power consumption? A: Each cabinet has 3 sets 300W power, that is 900W. The max power consumption is 80%, that is 720W per cabinet. The average consumption is 20%, that is 180W. And If we choose LEDFUL energy saving solution, we can save 40% power consumption. 2.Q:Do you provide the structure with the screen together?
A: We suggest to customize the structure in your local market, because it is big and heavy, it will cost too much for shipping. We shall provide the structure CAD Drawing, so that you can customize it easily. 3.Q:How to control it?
A:Wifi, 4G, cloud, USB, remote control.
4.Q: Are you trading company or manufacturer?
A: LEDFUL is a professional LED display manufacturer, having been enrolled in led display industry with professional
R&D team and skilled QC team for 13 years.
5.Q: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management.
Support APP/Phone/WIFI /pad/Laptop/PC/Cloud control. It's very easy and convenient to control.
6.Q: What is your best service?
A: One to one sales engineer to customer responsibility system. We will do:
1) Know your project and provide the best solution for it.
2) Track your order and let you know each step and detail of it.
3) Teach you how to install and use the screen.
4) Care the subsequent use of your screen and ensure vour after -sales service be well.
7.Q: How about your Warranty Term?
A: 3-year warranty. we have professional after-sale team to solve your any questions after you placed an order.
And your exclu-sive sales engineer will also help you to get over any problems. LEDFUL, Makes The World More Colorful.

---
