DS200ACNAG1ADD GE Controller module for petrochemical and natural gas

Product Details

Product Description

Product Description
DS200ACNAG1ADD GE Controller module for petrochemical and natural gas
DS200ACNAG1ADD GE Controller module for petrochemical and natural gas
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
The DS200ACNAG1ADD is an ARCNET (Attached Resource Computer Network) Card manufactured by General Electric for their Mark V series. The Mark V is part of GE’s successful Speedtronic line of gas/steam turbine management systems. This series has been managing heavy-duty turbine systems since the 1960s, with GE developing more reliable, advanced systems as technology allowed. The Mark V is built with triple-redundant backups on all critical controls and protection parameters and includes such features as built-in diagnostics and online maintenance.
The DS200ACNAG1ADD card provides a connection point for ARCNET LAN communications within the MKV system. Board signals travel on a pathway between the main processor board (LDCC,) through the ARCNET board, to the turbine control operator interface and back again. These signals travel via co-axial cables.
The DS200ACNAG1ADD is a small circuit board with few components. The board has four metal film resistors (R1 through R4,) three capacitors (C1 through C3,) and one diode. Two factory-drilled holes located on either side of the board have a metal washer inserted into their opening. These two openings are marked as GND1/GND2. Two relays are located near the bottom edge of the board. Both relays include a relay diagram on their top surface. Relay diagrams are visual representations of the relay logic that allows the relay to function.

---
