Nr13 Certified Custom High Pressure Hot Water Storage Tank / Stainless Steel

US$130,000.00
1-4 Pieces
US$125,000.00
5+ Pieces

Basic Info.

Model NO.
C-10/6.55
Function
Storage Pressure Vessel
Application
Liquid
Material
Stainless Steel
Pressure
1.6MPa≤p<10.0MPa
Storage Medium
Moncombustible/Nontoxic
Pressure Level
Medium Pressure (1.6MPa≤p<10.0MPa)
Condition
New
Corrosion Allowance
0mm
Installation Method
Vertical
Material Spec.
304
Design Pressure
7.2MPa
Test Pressure
10.1MPa
Transport Package
Iron Frame
Specification
10m³
Trademark
TK
Origin
China
HS Code
73110090
Production Capacity
20

Product Description

CODE:ASME SECT.VIII DIV.1 2021 EDITION
Code Certification:ASME U
Operating Pressure : 6.55MPa
Design Pressure : 7.2MPa
Temperature: 250ºC
Minimum design metal temperature(MDMT) at MAWP:-20ºC at 7.2MPa
Hydrostatic test pressure:10.1MPa at 0-48ºC
Medium name:Water
Corrosion allowance:0mm
Gross volume:10m³
Empty weight:13481kg

The products are designed and manufactured based on ASME VIII-1 code, meet the requirements of ASME, PED, AS1210 and other standards, as well as DOSH, CRN, EAC, MOM and other certification modes for you to choose. If you have any customized needs on the pressure vessel, you can contact us.
Zhejiang tank pressure vessel Co., Ltd. is a manufacturer specializing in the production of customized pressure vessels, we have ASME U and UM stamp authorization, and has obtained ISO9001-2015 quality system certification and PED Module H and Module H1 certificates issued by LRQA.
Standards or specifications that our products can comply with:
Product category Design Code Certifications
Air Receiver ASME VIII-1/GB150 ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Liquid Receiver ASME VIII-1/GB150 ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Separator ASME VIII-1/GB150 ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Adsorption Tank ASME VIII-1/GB150 ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
Heat Exchangers ASME VIII-1/GB150/GB151 ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS
