60m Detection Distance 0-90, 000ppm. M Uav Laser Methane Sensor for Drone

Product Description

Detailed Photos
60m distance detection drone use laser module methane 0-90000ppm.m

1. Long-distance detection: meet the methane and methane-containing gas leakage detection at a distance of 60 meters
2. Anti-cross interference: specific laser detection, only reacts to methane gas, not affected by environmental conditions

Performance

Specification			Min value	Typical value				Max. Value		Unit
Storage temperature			-40	-				70		ºC
Operating temperature			-20	-				50		ºC
Working humidity			-	-				98		%
Working pressure			-	101				-		kPa
Concentration range			0	-				90000		ppm·m
Effective distance measurement			0.5	-				60		m
Basic error			±10%@1000ppm·m
Minimum resolution			1							ppm·m
Communication Interface
TTL3.3V	Baud rate		-	9600				-		baud
Indicating photoelectric performance
Operating Voltage			2.7	3.3				5		V
Working current			-	50				-		mA
Signal light electrical performance
Operating Voltage			3.2	3.3				3.4		V
Working current			-	140				200		mA
Optical parameters
Detection light		Near infrared (1653nm) laser safety class Class I
		-			20		30		mW
Indicating light		Green light (532nm) laser safety class Class IIIR
		-				-	5		mW

---
