Vertical Milling Machine X5032 X5036 X5040

US$4,000.00-6,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

X5032 X5036 X5040

Type

Knee-and-Column Milling Machine

Object

Tool

Structure

Desktop

Milling Cutter Type

Vertical Milling Cutter

Milling Cutter Structure

Overall Welding Tooth

Controlling Mode

Artificial

Automatic Grade

Manual

Precision

High Precision

Certification

CE, RoHS, ISO 9001

Condition

New

Drill Capacity

25mm

Motor

2.2kw

Max Tapping Dia(mm)

M16

Table Size

1250X320mm

Taper

ISO40

Transport Package

Plywood Case

Specification

185kgs

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

84595900

Production Capacity

10 PCS/Month

Product Description

VERTICAL MILLING MACHINE FEATURES:
Model X5032 Vertical Knee-type Milling Machine, has extra travel in longitudinal, operating control adopts a cantilever panel. It is suit for milling flat,
inclined face, angular surface, slots by employing disc cutters, angular cutters. When mounted with the index, the machine will be able to perform milling
operations in gears, cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ± 45° . Spindle quill can be moved in vertical. The longitudinal, cross and vertical movements of the table can
both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.

SPECIFICATION	UNIT	X5032	X5032B
Table size	mm	320X1325	320X1600
T-slots (NO./Width /Pitch)		3/18/70	3/18/70
Longitudinal travel (manual/auto)	mm	700/680	900/880
Cross travel (manual/auto)	mm	255/240	255/240
Vertical travel (manual/auto)	mm	350/330	350/330
Rapid feed speed	mm/min	2300/1540/770	2300/1540/770
Spindle bore	mm	29	29
Spindle taper		7:24 ISO50	7:24 ISO50
Spindle speed range	r/min	30~1500	30~1500
Spindle speed step	steps	18	18
Spindle travel	mm	70	70
Max.swivel angle of vertical milling head		±45°	±45°
Distance between spindle nose and table surface	mm	60-410	60-410
Distance between spindle axis and column guide way	mm	350	350
Feed motor power	kw	2.2	2.2
Main motor Power	kw	7.5	7.5
Overall dimensions(L×W×H)	mm	2294×1770 ×1904	2294×1770 ×1904
Net weight	kg	2900/3200	2900/3200
