CNC Gear Hobbing Machine

Product Description

The machine adopts FANUC 0i-MF/H CNC system and has function of six axes and four axes moving simultaneously,which with electronic gear box(EGB)technology.a single-cut or multiple -cut hobbing cycle,a variety of cutting method,the position compensation can be achieved by the CNC control system,It also can achieve variety of gearcutting,such as,straight tooth,helical tooth,multiple teeth,drum-shaped teeth,small taper teeth,spline gear,sprockets,worm gears,etc.,the machine is suitable for small and large batch production.
The interface of the machine is specialized and easy to operate
With fully closed machine cover,the machine appearance is prm and beautiful.The cooling system adopts a large ßow of cooling pump and static electricity absorbing mist device .With Clean and hygienic working environment.
Adopts radial locking mechanism,tangential tool shifting clamping mechanism and rotary clamping mechanism,the rigidity of the machine tool is improvedgreatly.Worktable adopts high precision double lead worm gear which is equipped with hydraulic damping gap-eliminate unit to ensure the adjacent accumulation accuracy of gears.
The tool holder is equipped with a hob tensioning mechanism,
facilitates the installation of the hob and improves the working
efpciency
It can be equipped with accessories suchas automatic loading and unloading system,debarring mechanism,etc.,which is convenient for building an automatic production line.

Technical Data
Tip Diameter of work-piece	600 mm	Worktable diameter	400 mm
Max.Module	12 mm	Table center holediameter	75H7 mm
Radial stroke(x)	50-400 mm	Total load	50kVA
Radial movement speed(Max)	3000 mm/min	Control system	FANUC 0i-MF
Tangential stroke(Y)	200 mm	Total machine weight	13000 kg
Tangential movement speed(Max)	2500 mm/min	Dimension (L×W×H)	3145×3135×3310 mm
Axial stroke(Z)	190-490 mm	Processing accuracy	GB/T10095.1-Grade 6
Axialmovement speed (Max)	3000 mm/min	Machine configuration
Tailstock travel	340-740 mm	Machine tool host	Machine tool adjustment pads
Spindle speed	600 rpm	Electric box	Off-machine knife calibration device
Spindle power	18.5 kw	Hydraulic system	Hydraulic automatic tooling (optional)
Swing angle of hob head holder	±45
		Cooling system	Automatic gear alignment device (optional)
Taper hole of tool rest spindle	φ32,φ40,φ50/7:24
		Magnetic chip removal device and chip collector	Deburring mechanism (optional
Maximum hob diameter ×length	170×260 mm
Worktable rotary speed	40 rpm	Static electricity absorbing mist device	Ring loader (optional)
Worktable load capacity	500 kg	Hob bar assemblyφ32,φ40,φ50	Circulation channel (optional

RFQ Q1: Are you factory ?
This machine is made by China top manufacturer, we are agent of the company to export the machines. We have rich experience in machines business.
Q2: Could we visit factory ?
Yes, This manufacturer is top manufacturer, welcome to check details with the technology team.
Q3, How about check business with us ?
We have international business manager would check your requirement, then we would show machines videos to you, so welcome to send inquiry to us. Factory manager would contact with you directly.
Q4: How about the delivery time?
Our machines are standard models, delivery time would be 3 months, some special big projects would beed 1 year .

---
