| General | ||
| Frequency range | VHF:136-174 MHz; UHF:350-390 MHz, 400-480 MHz, 450-520 MHz | |
| Channel Capacity | 160 | |
| Zones | 32 | |
| Channel Spacing | 12.5KHz/25KHz | |
| Operating Voltage | DC 7.4V (±20%) | |
| Battery Capacity | 2000 mAh | |
| Battery Life(5/5/90) | Digital 22 Hours, Analog 16 Hours | |
| Recording Time | 400 Hours | |
| Frequency Stability | ±1.5ppm | |
| Antenna Impedance | 50Ω | |
| Dimensions (L×W×H) | 57(L)* 32(W)* 119 (H)mm | |
| Weight | 239g(Including Battery) | |
| Transmitter | ||
| RF Output Power | High Power: 5W; Low Power:1W | |
| 4FSK Modulation | 12.5kHz Only data:7K60FXD; 12.5kHz data and audio:7K60FXE | |
| FM Modulation | 12.5 kHz:8K50F3E; 25 kHz:16KΦF3E; | |
| Modulation Limiting | +/- 2.5kHz @ 12.5kHz; +/- 5kHz @ 25kHz | |
| FM Noise | -40dB | |
| Conducted Emission | -36 dBm≤1GHz/-30 dBm≥1GHz | |
| Adjacent Channel Power | ≤-60dB | |
| Audio Response | +1/-3 dB | |
| Audio Distortion | 3% | |
| Digital Voice coder Type | AMBE3000 | |
| Receiver | ||
| Digital Sensitivity | 5% BER:0.25 uV | |
| Analog Sensitivity | 0.25 uV (12 dB SINAD) | |
| Intermodulation | 60dB | |
| Adjacent Channel Selectivity | 60 dB | |
| Spurious Response Rejection | 60 dB | |
| FM Noise | -40dB | |
| Audio Response | +1/-3 dB | |
| Audio output power | 1.5W | |
| Audio Distortion | 3% (Typical) | |
| Conducted Spurious Emission | -57dBm | |
| GPS Accuracy | Horizontal Accuracy≤-10m(with well signal) | |
| TTFF (Time To First Fix) Cold Start | <1 Minute (with well signal) | |
| TTFF (Time To First Fix) Hot Start | <10 Second (with well signal) | |
| Environmental Specifications | ||
| Working Temperature | -20ºC-+60ºC | |
| Storage Temperature | -30ºC-+85ºC | |
| Humidity | MIL-STD-810C/D/E/F Standard | |
| Vibration & Shock | MIL-STD-810C/D/E/F Standard | |
| Dustproof & waterproof | IP67 | |
