Vertical Drilling Machine Z5032c/1 Z5045c/1 Z5040c/1

US$2,500.00-4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
Z5032C/1 Z5045C/1 Z5040C/1
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Manual
Number of Shaft
Manual
Hole Diameter
Manual
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Max. Driiling Capacity
32mm
Max. Taping Capacity
Mt3
Max.Spindel Travel
130mm
Spindel Speed
80-1250rpm
Motor Power
0.75kw
Transport Package
Plywood Case
Specification
Cast Iron
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
845929000
Production Capacity
300

Product Description


Vertical Drilling Machine Z5032C/1 Z5045C/1 Z5040C/1
Drilling, milling and tapping
Head swivels 360 horizontally
Headstock and Worktable up & down perpendicularly
Super high column
Precision micro feed
Positive spindel lock
Distinct auto device for releasing tools, operate easily
Geared drive, lower noise
Product main technical Specifications:
Specifications Z5032C/1 Z5040C/1 Z5045C/1
Max. Drilling dia. 32mm 40mm 45mm
Spindle taper M.T.3 or R8 M.T.4 M.T.4
Spindle travel 130mm 130mm 130mm
Step of speed 6 6 6
Range of spindle speed 50Hz 80-1250 r.p.m 80-1250 r.p.m 80-1250 r.p.m
60Hz 95-1500 r.p.m 95-1500 r.p.m 95-1500 r.p.m
Step of spindle auto-feeding 6 6 6
Range of spindle auto-feeding amount 0.06-0.30mm/r 0.06-0.30mm/r 0.06-0.30mm/r
Min.distance from spindle axis to column 290mm 290mm 290mm
Max.distance from spindle nose to worktable 700mm 700mm 700mm
Max.distance from spindle nose to stand table 1125mm 1125mm 1125mm
Max.travel of headstock 250mm 250mm 250mm
Swivel angle of headstock(horizontal) 360° 360° 360°
Max.travel of worktable bracket 600mm 600mm 600mm
Table Size 730×210mm 730×210mm 730×210mm
Size of stand worktable of avaliability 417×416mm 417×416mm 417×416mm
Forward and afterward travel of worktable 205mm 205mm 205mm
Left anf right travle of worktable 500mm 500mm 500mm
Vertical travel of worktable 570mm 570mm 570mm
Motor Power 0.75kw 1.1kw 1.5kw
speed of motor 1400rpm 1400rpm 1400rpm
Coolant pump power 0.04kw 0.04kw 0.04kw
Net weight/Gross weight 437/500kg 442/502kg 443/505kg
Packing size 1850x750x1000mm 1850x750x1000mm 1850x750x1000mm
