Stainless Steel Single-Stage High Viscosity Chemical Circulating Magnetic Drive Pump

Product Description

Plastic Magnetic Coupled Pumps Product Description
Magnetic Coupled Pumps are manufactured from polypropylene and PVDF thermoplastic materials. The pump technology is specifically manufactured for operation with corrosive chemicals associated with many industries. The design is unique given no seals are used to give the closed solution pump containment. The pump is operated by synchronizing magnetic forces from a drive magnet, connected to an electric motor, and the pump impeller positioned inside the pump. The assembly of the pump is simple and requires very little maintenance.
Magnetic Coupled Pumps have high tolerances, with no close touching parts between the pump impeller and suction casing. This gives an advantage when transferring solutions that have very fine particles present and liquids that can be prone to crystallization. They have a limited run-dry capability and can achieve flow rates between 0 and 1000 l/min.

Product Parameters

TYPE
PP	PVDF	PPS	Inlet Size	Oulet Size	Max flow(LPM)	Max head(M)	Power(kw)
DJ65PPE	DJ65KV	DJ65PPS	3/4”	3/4"	50	5	0.065
DJ150PPE	DJ150KV	DJ150PPS	1''	1''	90	7	0.15
DJ370PPE	DJ370KV	DJ370PPS	1''	1''	120	9	0.37
DJ550PPE	DJ550KV	DJ550PPS	1”	1”	160	15	0.55
DJ750PPE	DJ750KV	DJ750PPS	1-1/2"	1-1/2"	240	15	0.75
DJ1100PPE	DJ1100KV	DJ1100PPS	1-1/2"	1-1/2"	350	17	1.1
DJ1500PPE	DJ1500KV	DJ1500PPS	2"	1-1/2"	400	23	1.5
DJ2200PPE	DJ2200KV	DJ2200PPS	2"	1-1/2"	500	26	2.2
DJ3750PPE	DJ3750KV	DJ3750PPS	2- 1/2”	2”	800	31	3.75
DJ5500PPE	DJ5500KV	DJ5500PPS	2- 1/2”	2”	980	35	5.5
DJ7500PPE	DJ7500KV	DJ7500PPS	2- 1/2”	2”	1000	38	7.5

---
