Jwell Jwz-Bm Solar Float Blow Molding Machine for Solar Panel High-Quality PV Floating Applications, PV Floats with Customizable Features

Product Description

Product Parameters

Model	Unit	BM500	BM1000
Die head structure	Accumulating type	Accumulating type	Accumulating type
Main screw diameter	mm	120	135
Max plasticizing capacity(PE)	kg/h	350-450	550-650
Driving motor	KW	132	160
Accumulating volume	L	26	45
Oil pump motor power	KW	30	45
Clamping force	KN	800	1800
Space between platen	mm	500-1400	700-1900
Heating power of die head	KW	25	38
Machine dimension L*W*H	m	8.5*5.5*5.8	10.28*6.2*7.3
Machine weight	T	45	63
Total power	Kw	240	302

Detailed Photos

Product Description
Product Features: Customizable Design: Adaptable platen type and size to suit different product dimensions. High Efficiency: Equipped with a high-output extrusion system for optimal productivity. Advanced Control System: Features a hydraulic servo control system for precise and stable operation. Versatile Options: Optional double-layer co-extrusion system and bottom sealing capabilities. Core Pulling Mechanism: Includes optional product eject and core-pulling movement for enhanced functionality. Product Description: The JWZ-BM Solar Float Blow Molding Machine is an advanced solution tailored for the production of high-quality solar PV floating platforms. This machine integrates a high-output extrusion system with an accumulating die head, ensuring efficient and consistent performance.
With its customizable platen type and size, the machine is versatile enough to accommodate a wide range of product dimensions. Advanced features such as the hydraulic servo control system and optional double-layer co-extrusion capabilities offer precise control and flexibility in production. Additionally, the core-pulling mechanism and product eject options streamline the manufacturing process, making it a reliable choice for solar energy applications.
Product Application: Renewable Energy Industry: Manufacturing solar PV floating platforms for water-based solar farms. Environmental Applications: Creating durable and eco-friendly floating structures for renewable energy systems. Company Profile

---
