Automatic Fibre Cutting Machine /rag cutter /waste cloth cutting machine
Contact person:Ms Jenny
Phone:0086-13673672593
Skype:taizy2037
1.Brief introduction:
1.Products use a variety of high quality materials, after hundreds of process precision processing and into. Broad
scope, can quickly cut up all kinds of scrap cloth, cotton waste yarn, used clothing, cotton, chemical fiber, linen,leather, plastic film,
nonwoven fabric, paper, trademark and so on a wide range of Angle materials (the other can be equipped with strong magnetic separation, case the hard iron metal injury blades),
2.the chopped material uniform size, length of arbitrary adjustable. Whole mobile convenience, stable and reliable work, convenient maintenance, high production efficiency,
3.can solve a lot of manual labor chop cut, for the next step of opening and rework process to do good, is your ideal choice.
4.In addition,it can meet the requirement of best quality,high output,low cost and also has a feature of reasonable structure,easy to operation and safe production and so on.
2.Technical parameter:
Model
| TZ500A
| TZ500B
| TZ800A
| TZ800B
| TZ800C
| TZ800D
| TZ1200A
| TZ1200B
|
Motor
| 3 kw
| 3 kw
| 3 kw
| 4.5 kw
| 5.5 kw
| 7 kw
| 9 kw
| 9 kw
|
Size
(m)
| 1.8*1.0*1.1
| 3.2*1.0*1.1
| 3.2*1.0*1.1
| 6.0*1.0*1.1
| 6.0*1.4*1.2
|
Capacity
| 300 kg/h
| 500 kg/h
| 800 kg/h
| 1000-1500 kg/h
|
Cutting frequency
| 288 time / min
| 432
/min
| 1036
time/min
| 777
time/min
| 1036
time/min
|
Cutting size
| 3-300 mm
(fixed measure per time)
| 3-150mm
( 3 size permited per time )
| 3-150mm
( 3 size permited per time )
|
Rotary Cutter quantity
| 2 pieces
| 2 pcs
| 2-3 pcs
| 4 pcs
| 6 pcs
| 8 pcs
|
Feeding Belt
| 1000*350mm
| 1400*350 mm
| 2800*350 mm
| 2800*700 mm
|
Out-put Belt
| No
| 1400*350mm
| 1400*350 mm
|
| 2800*350 mm
| 2800*700 mm
|
Cutting thickness
| 20 mm
| 30mm
| 30-50 mm
| 30-60 mm
|
3.Photo show:
