Different Shape and Size Wheat Flour Mill

Product Description

Product parameters
Different model products(from 9fc-800 to 9fq-200)
9FC-800 Disk Mill
Main Features:
9FC-800 is an efficient disk mill. It is popular in large chemical industry, Pharmaceutical manufacture, Monosodium (glutamate powder) factory, Fodder factory, Gypsum powder factory, Metal calcium works, Paper-making factory, Soya bean cake factory, Wine factory etc. It is High yield, low power consumption, stable operation, easy handling.
Main Specifications:

Motor Power: (4 poles)	45-55KW	Crushed Wheat (1.5mm sieve)	8000kgs/h
Speed of Main shaft:	2180r/min	Crushed Corn (1.2mm sieve)	5600kgs/h
O.D of Rotator:	800mm	Crushed Sorghum (0.6mm sieve)	4800kgs/h
Long Hammer:	8 PCS	Crushed Soya bean (0.6mm sieve)	3800kgs/h
Short Hammer:	8 PCS	Crushed Rice (0.3mm sieve)	1800kgs/h
Round Teeth:	16 PCS	Weight (without motor):	980kgs

9FC-600 Disk Mill
Main Features:
9FC-600 is an efficient disk mill. It is popular in medium chemical industry, Pharmaceutical manufacture, Monosodium (glutamate powder) factory, Fodder factory, Gypsum powder factory, Metal calcium works, Paper-making factory, Soya bean cake factory, Wine factory etc. It is High yield, low power consumption, stable operation, easy handling. From the energy-saving, efficient, durable and so on, after installing self-feeding, blower and cyclone, it could be reducing the operator's labor intensity.
Main Specifications:

Motor Power: (4 poles)	30-37KW	Crushed Wheat (1.5mm sieve)	3500kgs/h
Speed of Main shaft:	3300r/min	Crushed Corn (1.2mm sieve)	2500kgs/h
O.D of Rotator:	600mm	Crushed Sorghum (0.6mm sieve)	2000kgs/h
Long Hammer:	5 PCS	Crushed Rice Husk (1.8mm sieve)	1400kgs/h
Short Hammer:	5 PCS	Crushed Rice (0.3mm sieve)	660kgs/h
Round Teeth:	10 PCS	Weight (without motor):	520kgs

9FC-500 Disk Mill
Main Features:
9FC-500 is an efficient disk mill. It is popular in medium chemical industry, Pharmaceutical manufacture, Monosodium (glutamate powder) factory, Fodder factory, Gypsum powder factory, Metal calcium works, Paper-making factory, Soya bean cake factory, Wine factory etc. It is High yield, low power consumption, stable operation, easy handling. From the energy-saving, efficient, durable and so on, it is much better than FFC-600 disk mill. After installing self-feeding, blower and cyclone, it could be reducing the operator's labor intensity.
Main Specifications:

Motor Power: (4 poles)	22-30KW	Crushed Wheat (1.5mm sieve)	2500kgs/h
Speed of Main shaft:	3300r/min	Crushed Corn (1.2mm sieve)	1800kgs/h
O.D of Rotator:	500mm	Crushed Sorghum (0.6mm sieve)	1500kgs/h
Long Hammer:	5 PCS	Crushed Rice Husk (1.8mm sieve)	1000kgs/h
Short Hammer:	5 PCS	Crushed Rice (0.3mm sieve)	500kgs/h
Round Teeth:	10 PCS	Weight (without motor):	460kgs

9FC-360 Disk Mill
Main Features:
9FC-360 Disk Mill is mainly suitable for small Chemical Plant, Fodder factory, Large individual farms and Households processing. This mill has the advantages of high yield, low power consumption, stable operation, safety and reliability, convenient assemble and disassemble. The Mill is installed self-feeding, Blower and Cyclone that will be more labor saving, energy saving and longer durable, it is much better than FFC-45 Disk Mill.
Main Specifications:

Motor Power: (4 poles)	7.5-11KW	Crushed Wheat (1.5mm sieve)	1100kgs/h
Speed of Main shaft:	4200r/min	Crushed Corn (1.2mm sieve)	950kgs/h
O.D of Rotator:	360mm	Crushed Sorghum (0.6mm sieve)	480kgs/h
Long Hammer:	5 PCS	Crushed Rice Husk (1.8mm sieve)	550kgs/h
Short Hammer:	5 PCS	Crushed Fodder (2.5mm sieve)	2000kgs/h
Crushed Soya bean(0.6mm sieve)	320kgs/h	Weight (without motor):	165kgs

9FC-320 Disk Mill
Main Features:
9FC-360 Disk Mill is mainly suitable for small Chemical Plant, Fodder factory, Large individual farms and Households processing. This mill has the advantages of high yield, low power consumption, stable operation, safety and reliability, convenient assemble and disassemble. The Mill is installed self-feeding, Blower and Cyclone that will be more labor saving, energy saving and longer durable, it is much better than FFC-37 Disk Mill.
Main Specifications:

Motor Power: (4 poles)	7.5-11KW	Crushed Wheat (1.5mm sieve)	900kgs/h
Speed of Main shaft:	4600r/min	Crushed Corn (1.2mm sieve)	800kgs/h
O.D of Rotator:	320mm	Crushed Sorghum (0.6mm sieve)	350kgs/h
Long Hammer:	5 PCS	Crushed Rice Husk (1.8mm sieve)	400kgs/h
Short Hammer:	5 PCS	Crushed Fodder (2.5mm sieve)	1500kgs/h
Crushed Soya bean(0.6mm sieve)	260kgs/h	Weight (without motor):	135kgs

9FC-230 Disk Mill
Main Features:
9FC-230 Disk Mill is suitable for families and small farms to use. This mill has the advantages of high yield, low power consumption, stable operation, safety and reliability, convenient assemble and disassemble. From its economy, durability, higher efficiency is better than FFC-20 & FFC-23 Disk Mill.
Main Specifications:

Motor Power: (4 poles)	2.2-3KW	Crushed Wheat (1.5mm sieve)	300kgs/h
Speed of Main shaft:	6600r/min	Crushed Corn (1.2mm sieve)	240kgs/h
O.D of Rotator:	230mm	Crushed Sorghum (0.6mm sieve)	150kgs/h
Long Hammer:	3 PCS	Crushed Soya bean(0.6mm sieve)	120kgs/h
Short Hammer:	3 PCS	Weight (without motor):	65kgs

9FQD-330/450 STRAW KNEADING DISK MILL
Main Features:
9FQD-330/450 Mill is with reasonable structure, beautiful appearance, practicality, easier maintenance, it is suitable for grinding corn, rice, soya bean and other gains. Meanwhile have the applications of cutting rubbing corn, straw, hay and potatoes seedling, weed etc, it could be crushed into powder or soft fodder, one machine are multifunction.
Main Specifications:

	Motor Power	Stator	Rotor	Speed of main shaft	O.D of Rotator	Hammer	Crushed Corn (2mm sieve)	Crushed Straw
9FQD-330	3.0KW	1PCS	3PCS	4200r/min	330mm	16 PCS	560kgs/h	280kgs/h
9FQD-450	7.5KW	1PCS	3PCS	3800r/min	450mm	16 PCS	1500kgs/h	680kgs/h

9FQ300 & 9FQ-200 STRAW GRINDER
9FQ-300 & 200 Straw Grinders are used for farmers to crush fodder, grains, hay and straw etc.
Main Specifications:

	Motor Power	Speed of main shaft	O.D of Rotator	Hammer	Crushed fodder (8-10mm )	Crushed fodder (2.5-5mm)
9FQ-300	3.0KW	4200r/min	300mm	24 PCS	1500kgs/h	1000kgs/h
9FQ-200	1.5KW	4000r/min	200mm	24 PCS	800kgs/h	500kgs/h

Features
1.Compact shape, parts repair and replacement easy
2.Mechanical stability, low energy consumption, crushed, crush phenomenon, not raise he crushed temperature
3.Lower energy consumption, compared with the traditional omnipotent pulverize, it could save 30% power
4.Equipment structure compact, floor space small
5.In crushing box no stitch line, no dead space, easy to unpick and wash, disinfect, change variety expediently, meet with the GMP standard
6.The scope of shatter granularity, the grain diameter of end product is 20-200 item scope adjusted arbitrarily; machinery roundly, the output is 15~500kg/h machinery optionally
Working ways
This machine uses the relative motion between movable and fixed teeth disc, and the raw materials is grinded by the comprehensive actions such as impacted by teeth, friction, impact between raw materials.
The crushed material can be discharged through the grinding chamber. Moreover, different size of granule or powder can be got through exchanging screen with different mesh.
Its inner wall is processed finely, so it is smooth and level, which overcomes the shortcomings existed in the old model such as roughness, accumulated powder.
To use it better , you might put your ingredient in no more than the position of machine's hopper 2/3.
Application scope
1.Grain: corn, rice, wheat, oats, barley, sorghum, buck, wheat, millet, green beans, green beans, cassava.
2.Spices: mint, cinnamon, star anise, fennel, citronella, osmanthus flowers, lemon grass, ginger, turmeric, Chinese prickly ash, black pepper, white pepper, pepper, garlic, Chloe, fennel, cloves.
3.Seasonings:white sugar, salt, monosodium glutamate, chicken essence etc
4.Chinese herbs: ginseng, jujube, pseudo-ginseng, angelica, etc
5.Food: coffee, cocoa beans, puffed food, etc
6.Wet ingredients:chili sauce,cabbage,tomato,shrimp,various fruits etc.
7.Crisp Chemicals.
Company Profile
Jinan Sensi Industries Co.,Ltd is specialized in manufacturing agricultural processing machinery. Our Disk Mill, Flour Mill, Rice Mill, Oil Expeller and Meat Mincer could be process Corn, Wheat, Paddy, Soybean, Peanut and other grains. Our machines are sold into India, Egypt, Sudan, Kenya, Morocco, Australia and USA etc. We still keep the quality is the life, Innovation for development, from the wonderful appearance to inner structure, from best package to safety delivery, each action are our best service for the customers.
Our trademarks are SMECH, SENCHE, DRAGONSATR and NASTAR, we also could make OEM under customers requirement.
We also registered a international offshore company SENSI INDUSTRIES LIMITED for management some import & export business.
We are willing to build trusty business relationship and friendship with you.
Our service:
1.Warranty: 12 months after selling
2.Certificates: As your requirements
3.Prepare goods ready according to our agreement
4.Quality Management System: ISO 9001:2008
5.Advanced technique, Strong R&D capability
6.Wide range of product types
7.OEM quality, factory price, fast delivery and efficient service
8.Keep stock for emergency orders
FAQ:
Q1: Can I add my logo on the products?
A1: Yes, OEM is available for us.
Q2: Do you have inspection procedures for the products?
A2: 100% self-inspection before packing.
Q3: Can you accept small qty?
A3: Yes, small qty accept & quick delivery.
Q4: Can I have a visit to your company before the order?
A4: Sure, welcome to visit our company.
Here is our company address: No. 112 Jiefang Road, Jinan, Shandong, China .
Q5: Are you trading company or manufacturer ?
A5: We are factory.

Q6: How long is your delivery time?
A6: Generally it is 5-10 days if the goods are in stock. or it is 45-60 days if the goods are not in stock, it is according to what kind of machine you need
Q7: What is your terms of payment ?
A7: 30% T/T in advance ,70% balance before shipment or Negotiable
If you have another question, please feel free to contact us as below
Contact us:
JINAN SENSI INDUSTRIES CO., LTD
NO.112 JIEFANG ROAD, JINAN, CHINA
TEL:86-531-55583071 FAX:86-531-55583072
Mobile : 0086-133 3513 2227

---
