Self recovery professional electric winch, best choice for off-road enthusiast!
| |
| NINGBO CHIMA WINCH CO., LTD. |
| No. 38 DONGBEI RD, DONGQIAO TOWN, YINZHOU DISTRICT, NINGBO, 315157 ZHEJIANG,CHINA |
| |
| 4WD WINCH QUOTATION |
| Customer: | Quote Date: Jan. 8th, 2015 |
| Supplier: NINGBO CHIMA WINCH CO., LTD | | | |
| FROM | Zhejiang Province, China | TO | |
| TERMS OF PAYMENT | TT or L/C | PACKING | EXPORT CARTON |
| TIME OF SHIPMENT | FOB NINGBO |
| Product info. | Points | Picture |
| Model | 12000lbs |
|
| Unit Price(USD) | $165.00 |
| Performance | 12VDC / 24VDC |
| Single line rated pull | 12000lb(5454kgs) |
| Motor | 6hp/4.5kw,Series Wound |
| Control | Remote switch,11.5ft(3.5m)lead |
| Gear train | 3 Stage Planetary |
| Gear reduction ratio | 265.2:1 |
| Braking Action | Automatic In-The-Drum |
| Drum size | Diameter2.5"(63.5mm) Length 8.8"(224mm) |
| Cable | 9.5mm*26m |
| Fairlead | 4-Way Roller Fairlead |
| Wireless Remote Control | Included |
| Battery | Recommended:650CCA minimum for winching |
| Battery Leads | 2 gauge,72"(1.83m) |
| Finish | Black/Dark Grey |
| Weight | N.W.88lbs(42kg) G.W.95lbs(46kg) |
| Overall dimentions | (LxWxH)20.9"x6.3"x8.35"(530x160x212mm) |
| Mounting Bolt Pattern | 10.00±0.015"x4.50±0.010"(254x114.3mm) |
| | |
