Heavy-Duty CNC Mill Lathe Machine, CNC Turnmill for Industrial Use

Product Description

Product Description
-Robust Box Guideways: Engineered for heavy-duty cutting, offering exceptional stability and precision.
-Innovative 30° Slanted One-Piece Bed Structure: Designed for unparalleled rigidity and strength under intensive operations.
-Stabilized Unit Structure: Expertly minimizes thermal displacement, ensuring consistent performance.
-Integrated Processing: Achieve seamless operations with synchronized control of the main spindle.
--Sophisticated Multi-tasking: Enhanced by the wedge type BMT turret for versatile applications.
Remarkable Rapid Traverse Rate: Achieves an impressive 30m/min on the Z-axis for efficient processing.
-Ergonomically Crafted: Ensures easy access to both chuck and tool, accentuating user convenience.
Product Parameters

Description			Unit	HD3105M
Capacity	Swing over bed		mm	Φ740
	Swing over front door		mm	Φ640
	Swing over saddle*		mm	Φ480
	Max. turning diameter		mm
	Max. turning length		mm	672
	Bar workiing diameter		mm	Φ740
Travels	Travel distance	X-axis	mm	260
		Z-axis	mm	730
Feedarates	Rapid traverse	X-axis	m/min(ipm)	24
		Z-axis	m/min(ipm)	30
Spindle	Spindle speed(Belt Type)		r/min	2,800
	Spindle nose			A2-8
	Spindle through hole diameter		mm	Φ91
	Min. spindle indexing angle(C-axis)		deg	0.001
Turret	No. of tool stations		st	12
	OD tool size		mm	25
	Boring bar diameter		mm	50
	Indexing time(1st swivel time)		s	0.15
	Rotary tool spindle speed		r/min	4000
Tail stock	Quill diameter		mm	Φ100
	Quill bore taper(Live)			MT5
	Compressed air supply		mm	120
Motors	Main spindle motor		kW(Hp)	15/18.5
	Collant pump motor		kW(Hp)	3.7
Power source	Electric power supply(Rated capacity)		kVA	35
Machine size	Machine height		mm	1755
	Machine dimension	length	mm	3284 3285
		width	mm	1817
	Machine weight		kg(lb)	5800

ALL-IN-ONE BED DESIGN: An integrated approach to elevate performance and reliability.
Optimal Structural Analysis
Our structural analysis enhances design sophistication by increasing tool post body strength while reducing machine height, maintaining dynamic rigidity even during the most demanding heavy-duty cuts.
Moreover, the HD-SY Series boasts a 30-degree bed slope, optimizing stability during machining processes.
Integrated Coolant Tank
Ingenious Design: Features a strategically positioned coolant tank at the bed's front for heightened user convenience, with efficient chip removal from the right side.
Box Guideway
Each axis of the HD-SY Series is fortified with Box guideways, enhancing travel ability and delivering exceptional vibration dampening during high-intensity cutting operations.
Sealed GIB Structure
The X-axis is meticulously engineered with a sealed GIB structure, safeguarding against turcite chip damage for enduring durability.
Rapid Traverse Rate (X/Z)
HD 3105M 24/30 m/min: Ensuring swift and dynamic movements to boost productivity.
Travel (X/Z)
HD 3105M 260/730 mm: Offering expansive travel dimensions for diverse applications.
Mill Turret
The BMT turret is engineered with precision, securing tools with four bolts and keys, delivering unmatched reliability in both rigidity and precision.
Mill Tool Holder
With enhanced machining capabilities, the inclusion of straight and angular milling head tool holders allows for versatile machining from side operations to I.D. processes.
Suzhou Wugan Intelligent Equipment Co., Ltd. stands out in producing state-of-the-art CNC lathes and turning centers, designed with the latest global lathe technology. These products blend high rigidity, precision, and productivity with an exquisite design, offering customers unparalleled cutting performance. To meet elevated customer demands, we offer high-performance mill-turn models, capable of turning, milling, and drilling in one machine. This versatility not only boosts output capacity but also adapts seamlessly to diverse customer processing needs, making our lathes a top choice for various applications.

---
