Mechatronics Training Equipment Didactic Equipment Flexible Manufacturing System Fms

Product Description

SS606 Mechatronics Training Equipment Didactic Equipment Flexible Manufacturing System FMS
I. Didactic Equipment Overview
This system is an integrated training system based on industrial flexible production line manufacturing system, its content covers industrial light, machine, electricity integration and other automatic control application technologies, it does real-time data exchange through upper computer WINCC configuration software, and it makes all the unit platforms and actuators in the system form an integrated industrial control network, hardware supports 485, MODBUS, DP network communication modes.
The whole system consists of six parts, six workstations of simulation industry flexible manufacturing system, namely: material loading test station, handling station, processing station, installation handling stations, installation station and classification storage station, each station is equipped with a Siemens PLC as main control unit, integrated control training of the six stations can be carried out through the communication between the PLC according to requirement, or a few stations which are adjacent constitute the small flexible system to do training, you can also do separate control training for any station. It is with reasonable configuration and rich contents, realizes the execution control from upper computer configuration data monitoring to the bottom of the system, covers the various elements of modern industry light, machine, electricity integration control technology application, and meets the design, installation, commissioning and programming of complex systems and other topics.
The system realizes production line sensor detection, transmission processing, intelligent control, and execution-drive production line, you can learn and master the pneumatic technology, motor drive and control technology, PLC control technology, industrial communication technology, sensor application technology, mechanical transmission technology, robot technology and other discipline contents.
II. Didactic Equipment Technical Parameter
1, Control cabinet main circuit power supply:single phase AC220V ± 10% 50Hz
2. Control cabinet control loop power supply:DC24V
3. Temperature:-10 ºC ~ 40 ºC,
4. Environmental humidity:≤ 90% (25 ºC)
5. CompositionThis system include 6 independent working stations, they interconnect and combine a whole manufacturing system, please see below flow chart for system working
We also supply engineer educational equipment,vocational training equipment,didactic equipment,technical training equipment,industrial training equipment,industrial automation trainer,civil training equipment,innovation teaching model,scientific laboratory equipment,teaching material,school experiment equipment,physical educational aids,FA trainer,electrical engineer lab,mechanical laboratory,mechatornics trainer,automobile trainer,vehicle trainer,tutor model,mechatronics training equipment,hydraulic workbench,pneumatic trainer,electrical machine,elevator trainer,lift teaching model,modular product system,flexible manufacture system,PCB processing educational system,renewable training system,sensor teaching equipment,transducer trainer,fuel injection demo model,woodworking workshop cabinet,welding workshop fume extractor,building automation trainer,water tank trainer,process control trainer,vice workbench,home appliance trainer,RF trainer,antenna teaching equipment,microwave educational kit,radar teaching model,ABS instructional package,PLC trainer,electronics demonstrational model,industrial network communication trainer,science instrument,air conditioner trainer,automobile simulator for technical schools, college, university.

Dimensions	2240 × 1500 × 1400 mm ( L × W × H )
Air supply pressure	0.5 ~ 0.6Mpa
Machine capacity	≤ 1KVA

---
