System | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor | Industrial-grade processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded Linux | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Interface | Web, Local GUI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Recorder | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AcuPick AI by Camera + Recorder | Max. 64-channel, 1 combined event per channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance AI by Recorder (Number of Channels) | Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Performance of AI by Camera (Number of Channels) | All channels (64 targets/s) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes | Gender; age group; glasses; expressions; face mask; beard | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Recorder (Number of Channels) | Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection Performance of AI by Camera (Number of Channels) | 64 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Database Capacity | Up to 40 face databases with 300,000 images, with a total capacity of 48 G. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Recorder (Number of Channels) | Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Performance of AI by Camera (Number of Channels) | 64 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Recorder | 32-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD Plus by Camera | All channels (128 targets/s) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Metadata | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance of AI by Recorder (Number of Channels) | 8 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Metadata Performance of AI by Camera (Number of Channels) | 64 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Attributes | 9 human body attributes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Human Attributes | Top color, top type, hat, bag, age, gender and umbrella | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motor Vehicle Attributes | License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling, | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Non-motor Vehicle Attributes | Vehicle model, vehicle color, number of persons, helmet. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Vehicle License Plate Comparison | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ANPR by Camera (Number of Channels) | All channels (64 targets/s) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
License Plate Database Capacity | Blocklist and allowlist: 20,000 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio and Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Access Channel | 64 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Bandwidth | AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability | AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps;128-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps; 80-channel D1@30 fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output | 2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1-4) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-screen Display | Main screen: 1/4/8/9/16/25/36/64 Sub screen: 1/4/8/9/16/25/36 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression Standard | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MPEG4; MJPEG | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711u; PCM; G726 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone Access | iOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/profile T/Profile G); CGI; SDK | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | Chrome IE 9 or later Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Mode | Multi-address mode, load balance, fault tolerance and other network port binding modes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording Playback | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multi-channel Playback | Up to 16 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Record Mode | Manual; alarm; motion detection; scheduled | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backup Method | Portable hard drive, eSATA disk, burner, USB device and network | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Playback Mode | 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame 2. Full screen, backup (cut/file), partially enlarge, audio on/off | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Disk Group | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAID | RAID 0/1/5/6/10 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hot Swapping | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm | Motion detection; video tampering; video loss; scene changing, PIR alarm, IPC external alarm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Anomaly Alarm | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Alarm | Face detection; face recognition; perimeter protection (intrusion and tripwire); SMD Plus alarms; ANPR; people counting; stereo analysis; crowd distribution; heat map | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Linkage | Record; snapshot; IPC external alarm output; buzzer; log, preset; email | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1-channel RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 2-channel RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 16 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 8 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Disk Interface | 8 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
eSATA | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-232 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 | 1 × A/B | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDMI | 4 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VGA | 2 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | 2 (10/100/1000/2500 Mbps Ethernet port, RJ-45) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 100-240 VAC, 50/60 Hz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | <18 W (without HDD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 6.40 kg (14.11 lb) (without HDD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 10.35 kg (22.82 lb) (without HDD) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 444.0 mm × 456.6 mm x 95.0 mm (17.48" × 17.98" × 3.74") (W × D × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions | 570.0 mm × 570.0 mm × 226.0 mm (22.44" × 22.44" × 8.90")(W × D × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | -10 °C to +55 °C (14 °F to +131 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | 0 °C to +40 °C (+32 °F to +104 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 10%-93% (RH), non-condensing | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation | Rack or desktop | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2020, Class A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014+A11:2017 |
