Hzs 25m3 35m3 50m3 60m3/H China Cost Price Fixed Cement Concrete Concrete Batching Mixing Plant Stationary Machine Manufacturers

US$16,000.00-53,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HZs60
Shotcrete Type
Semi-Dry
Machining Process
Welded Molding Machine
Structure
Cylinder Type
Productivity
60m²/h
Feeding Height
1400mm
Vibrating Amplitude
0.8mm
Certification
ISO9001: 2000, CE
Condition
New
Machine Type
Batching Machine
Core Components
PLC, Gearbox, Mixer, Batch Station, Bucket Elevato
Product Name
Ready Mixed Concrete Batching Plant
Keywords
Concrete Batching Plant
Weight
15000kg
Capacity
35m3/H
Concrete Mixer Type
Double Horizontal Shaft Forced Mixer
Function
Mixing Sand Stone
Power
Cement
Transport Package
Bubble Wrap
Specification
1 CBM per hour
Origin
China
HS Code
84743100
Production Capacity
300

Product Description

HZS25 HZS35 HZS50 HZS60 HZS75 HZS90 HZS100 HZS120 HZS150 HZS180
Discharging Capacity (L) 500 750 1000 1000 1500 1500 2000 2000 2500 3000
Charging Capacity(L) 800 1200 1600 1600 2400 2400 3200 3200 4000 4800
Maximum Productivity(m³/h) 25 35 50 60 75 90 100 120 150 180
Charging Model Skip Hopper Skip Hopper Skip Hopper belt conveyor Skip Hopper belt conveyor belt conveyor belt conveyor Skip Hopper belt conveyor
Standard Discharging Height(m) 1.5~3.8 2~4.2 4.2 4.2 4.2 4.2 3.8~4.5 3.8~4.5 4.5 4.5
Number of Species of Aggregate 2~3 2~3 3~4 3~4 3~4 4 4 4 4 4
Maximum Aggregate Size(mm) ≤60mm ≤80mm ≤80mm ≤80mm ≤80mm ≤80mm ≤120mm ≤120mm ≤150mm ≤180mm
Cement/Powder Silo Capacity(set) 1×100T 2×100T 3×100T 3×100T 3×100T 3×100T 4×100T or 200T 4×100T or 200T 4×200T 4×200T
Mixing Cycle Time(s) 72 60 60 60 60 60 60 60 30 30
Total Installed Capacity(kw) 60 65.5 85 100 145 164 188 210 230 288




1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .

2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 8 years.

3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.

4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
