Platen Press for Rubber / Rubber Vulcanizer (ISO/CE) Xlb-Dq 600X600X2

Product Description

Application:
This vulcanizing machine is used for vulcanizing all kinds of rubber and plastic model products, and non-model products.
Feature:
1. The material of the piston is LT-P chilled cast iron, the surface is chilled cast iron of vanadium and titanium alloy hard and wearable. It is burnished and polishing by manpower. The hard surface depth can reach to 0.5-0.7mm.
The cylinder mateerial is QT500-7 ductile cast rion and the inside surface is high pressure and nitroger treatment, the surface is burnished and polishing by manpower too. The hard surface depth can reach to0.7-0.9mm.
The set of hydraulic cylinder contain pistin, cylinder, gland ring and the flange. The flange press the gland in order to pevent spillage oil. The material of the gland rig(XY) is oil resistance rubber.
The hydraulic system are fond and maching by ourself.
2. The electricit system we can useMITSUBISHI, DELTA, SCHNEIDER, Siemens etc. You can choose option what kind brand that you want
3. The hydraulic contain three sets low-prssure motor pump and one set high pressure motor pump.
You can also appointment brand of the motor and pump you want. Our engineer can redesign it according to you specific demand.
Technical Model:

Type	XLB-DQ400X400X2	XLB-DQ400X400X2	XLB-DQ600X600X2	XLB-DQ750X850X2(4)
Total Pressure(mn)	0.25	0.50	1.00	1.60
Plate Size(mm)	400X400	400X400	600X600	750X850
Daylight(mm)	125	125	125	125
Daylight No	2	2	2	2(4)
Piston Stroke(mm)	250	250	250	250(500)
Unit Area Pressure(kg/cm2)	20	31	28	25
Main Motor Power(Kw)	3	2.2	2.2	3
Overall Dimension(mm)	1300X800X1500	2400X550X1500	1401X680X1750	1900X950X2028
Weight(Kg)	1150	1300	3500	6500(7500)

Machine Overview:

---
