| US$1.00 | 1 Piece (MOQ) |
| Main parameters | |||
| Type | CD1604 | CD1804 | CD2104 |
| Drive type | 4WD 4×4 | ||
| Engine | (CN stage 3) | ||
| Engine Brand | YuChai | ||
| Engine Type | YC6J190-T301(TCI) | YC6J190-T306(TCI) | YC6J210-T305(TCI) |
| Max. Torque (Nm @ engine rpm) | (670-710)@1400-1700 | (700-735)@1400-1700 | (700-735)@1400-1700 |
| (N.m)/(rpm) | |||
| Displacement (L) | 6.494 | ||
| Fuel tank capacity (L) | 270+150 | ||
| Rating power of engine | 117.6 /2300 | 132.4 /2300 | 154.4 /2300 |
| kW/rpm | |||
| Fuel consumption @ nominal power | ≤250 | ||
| (g/kw.h) | |||
| Air Intake Type | TC | TC | TC |
| N / Displacement / | 6/6.494 | ||
| Air filter | dry type | ||
| Torque reserve | 31% | 30% | 32% |
| Transmission system | |||
| Clutch | Single disc multi pads - Dry clutch - 14" -- 14" | ||
| No. of gears | 24F+12R:4X3X(2+1) 16F+12R:(4X3X1+4X1X1)+(4x3x1) | ||
| Shift method | Synchronizer | ||
| Max. speed | 38.22km/h | ||
| Gear position | Command aside | ||
| Hydraulic system | |||
| Hydraulic output flow rate | 76.8 | ||
| (L / MIN) | |||
| Hydraulic output valve | 4ways/6ways | ||
| Working device | |||
| Three-point-linkage | 2N/3N | ||
| PTO Speed PTO | 540/1000 | ||
| Lifting Capacity (610mm)kN | 52 | ||
| Tillage depth adjustment | Draft /Position/Mix and Float | ||
| ,, | |||
| Parameter | |||
| The whole machine size (dimensions) mm | 5108X2466X3075 | ||
| () | |||
| Min. operation mass (kg) | 6380 | ||
| Mini turning Radius (m) | 5.5 | ||
| Rated traction force(KN) | 45 | 49 | 55 |
| Deck | Flat Deck | ||
| Wheelbase(mm) | 2805 | ||
| Minimum ground clearance (mm) | 450 | ||
| Cabin | Basic:HVAC Cabin,Opt.:Heating Cabin, | ||
| Front/rear wheel track / | 1900/1958(Front/Rear tyre /: 18.4-26/24.5-32") | ||
| 1900/(Inside 1828 outside 3156)(Front/Rear tyre /: 18.4-26/20.8-38"Double ) | |||
| Tyre size | Front: 18.4-26 Rear:20.8-38"Double/Front: 18.4-26 Rear:24.5-32" | ||
| Braking and steering | |||
| Braking system | Independent / Multi discs - oil immersed / Hydrostatically operated / -/ | ||
| Steering type | Hydraulic steering | ||
| Steering Angle (4 x4) | 52° | ||
