| US$13,800.00-15,000.00 | 1 Piece (MOQ) |
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 1735mm | ||||||||
| Arm length | 815mm | |||||||||
| Maximum Digging Reach | 3800mm | |||||||||
| Maximum Digging Depth | 1900mm | |||||||||
| Maximum Digging Height | 3335mm | |||||||||
| Maximum Dumping Height | 2165mm | |||||||||
| Min radius of gyration | 940mm | |||||||||
| Back-end radius of gyration | 940mm | |||||||||
| Maximum digging reach | 3700mm | |||||||||
| DIMENSION | (Length*width*height) travel position | 3630*1000*2150mm | ||||||||
| Wheel base | 750mm | |||||||||
| Min ground clearance | 115mm | |||||||||
| TECHNICAL PARAMETERS | Machine weight | 1600kg | ||||||||
| Rated Power | 13.6KW/19KW | |||||||||
| Volume Of Bucket | 0.04m3 | |||||||||
| Hydraulic system working pressure | 16Mpa | |||||||||
| Swing speed | 15rpm | |||||||||
| (High speed/low speed) | 0~2km/h | |||||||||
| Max digging force of bucket | 9.6KN | |||||||||
| Max digging force of arm | 8.5KN | |||||||||
| Ground pressure | 2.5Kpa | |||||||||
| Grade Climbing ability | <30° | |||||||||
