DIN 8077/8088 PPR Pipes and Fittings Pn20 Pn25 20X2.8mm 20X3.4mm for Water Supplying

Product Description

Product DescriptionProduct DescriptionASB PP-R Pipes are made of 100% new material such as TAIRIPRO, SINOPEC and HYOSUNG. ASB is totally following the Germany Standard DIN8077/8088 to process the Pipes. Now the Pipe series is from PN12.5 to PN25 and the dimension is from 20mm to 110mm. With the advantages like lightness, corrosion resistance and long life, ASB PP-R Pipes are accepted by customers from over 90 countries in the world.
Product Specification

Dimension	Average Dimension		Pipe Series
			S5	S4	S3.2	S2.5
			PN12.5bar	PN16bar	PN20bar	PN25bar
dn	dn,min	dn,max	Thickness
20	20.0	20.3	2.0	2.3	2.8	3.4
25	25.0	25.3	2.3	2.8	3.5	4.2
32	32.0	32.3	2.9	3.6	4.4	5.4
40	40.0	40.4	3.7	4.5	5.5	6.7
50	50.0	50.5	4.6	5.6	6.9	8.3
63	63.0	63.6	5.8	7.1	8.6	10.5
75	75.0	75.7	6.8	8.1	10.3	12.5
90	90.0	90.9	8.2	10.1	12.3	15.0
110	110.0	111.0	10. 0	12.3	15.1	18. 3

Product Parameters

Unit	Property	Value
ºC	Working Temperature	0-95
w/m.k	Thermal Conductivity	0.21
mm(m.k)	Thermal Expansion Coefficient	0.16
%	Longitudinal Retraction Rate(135ºC/1h)	≤3
g/10min	MFR (230ºC/2.16kg)	<0.5g/10min
g/cm	Density	0.94
Mpa	Tensile Yield Strength	≤40
%	Elongation	>50
Mpa	Elasticity Modulus	800
%	Impact Test(0ºC;2h;15J)	≤10

Our Advantages1-Good Appearance and Light Weight
The inner and outer walls of the product are smooth, the fluid resistance is small, the color is soft, the shape is beautiful, and the weight is only about 1/8 of the metal tube, which is convenient for transportation and installation.
2-Long Life
High pressure-resistant and high temperature resistant. ASB PP-R Pipe's life can be 50 years under normal conditions.
3-Hygiene
Green building materials, non-toxic, non-polluting, recyclable, not only for hot and cold water pipes but also for potable water systems
4-Good Thermostabilization
The Vicat softening point of the ASB PP-R pipe is 131.5ºC, it can be used for a long time when the working water temperature is 70 ºC, meeting the requirements of the hot water system in a real building.
5-Insulation and Energy Saving
The Thermal Conductivity of the ASB PP-R Pipe is only 0.21w/m.k, just 1/200 of the steel pipe
6-Easy installation
Using a hot-melt connection, a joint connection can be completed in several seconds. The pipe and fittings are made of the same type of raw material and the pipe-fitting joints reach the molecular level fusion, making it a whole system perfectly.
Testing CenterASB PPR water pipes are inspected from the materials to finished products, we testing the MTR, Hardness, Hydrostatic pressure and burst pressure, etc to make sure the quality is at the top level
Application Areas 1.Residential Apartments
2.Hospital, Hotel, School, Office, Public Places, etc.
3.Hot and Cold Water System, Potable Water System4.Solar System5.Rainwater Pipe Network6.Swimming Pool Pipe Network7.Agriculture, Garden Pipe Network8.Industrial Pipe Networks Such As Food, Chemical, Electronics, etc. Installation Illustration
Company ProfileASB specializes in the production of water supply piping systems and heating systems. The main products include PP-R pipes and fittings, aluminum-plastic PPR pipes, glass fiber PP-R pipes, aluminum-plastic composite pipes and fittings, HDPE pipes and fittings, PEX/PERT floor heating. Pipe, floor heating manifolds, brass ball valve and all kinds of brass parts.
ASB has passed the ISO9001 quality management system and ISO1400 environmental management system in the same industry through standardized management, strict testing and excellent service. At the same time, the company strictly controls the quality, and the products have passed the certifications of EU CE, Germany SKZ and Russia, Ukraine, Poland and other different standards. Products are exported to more than 90 countries and regions around the world including Germany, Britain, Poland, Russia, Mexico, Argentina, the Middle East, Southeastern Asia and Africa.
FAQ1. Are you a manufacturer or a trading company?We are the manufacturer since 1989, we have over 30 years' experience in this industry.2. What size of pipes can you make?16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm3. What colour of pipes can you do?White, Grey, Green, Blue
4. What packing coils are you offering?
Straight 3.8m/pc, 4m/pc, 5m/pcCoils, 50m, 100m/coil5. Which port is near your factory?NINGBO PORT or SHANGHAI PORT6. What's your Price Term?Usually, we offer based FOB NINGBO, CHINA. We can also quote CIF per your request.7. What's your Payment Term?The popular one is a 30% deposit and the balance before shipping.8. What's your Delivery Time?It depends on your Items and Quantity while for example, we can ship a 40HQ container of basic goods within one week.9. If you can accept OEM processing?Yes, we can do OEM and both ODM

---
